KT3100T
The Eaton Cutler-Hammer KT3100T is a thermal-magnetic circuit breaker designed for robust performance. This model supports an amperage rating of 100 A and is optimized for three-pole configurations, making it suitable for various applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for KT3100T
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Thermal-Magnetic Circuit Breaker |
| Product Line | Series C Circuit Breakers |
| Part Number | KT3100T |
| UPC | 786679266007 |
| Amperage Rating | 100 A |
| Number of Poles | 3 Poles |
| Voltage Rating (Maximum) | 600 VAC |
| Trip Unit Type | Thermal-Magnetic |
| Frame Type | KT |
| Interrupting Capacity | 35 kAIC @ 480 VAC (typical for KT series breakers) |
| Mounting Style | Bolt-on |
| Frequency Rating | 50/60 Hz |
| Instantaneous Trip Adjustment | Fixed (non-adjustable) |
| Number of Operations (Electrical Endurance) | 10,000 cycles (typical for KT breakers) |
The KT3100T circuit breaker is part of Eaton Cutler-Hammer's Series C offerings. This device represents a thermal-magnetic type designed to provide overcurrent protection in electrical installations.
Operating at a maximum voltage of 600 VAC, this breaker can handle significant loads. The unit is rated for 100 A and features three poles, suitable for comprehensive circuit protection. Its frame is specifically denoted as KT, which is engineered to support a high interrupting capacity of up to 35 kAIC, particularly at 480 VAC, ensuring reliable performance in fault conditions.
The device operates within standard frequency ratings of 50 or 60 Hz, accommodating various system requirements. The mounting configuration allows for secure bolt-on installation, facilitating integration into existing systems. An important characteristic is its instantaneous trip adjustment, which is fixed and non-adjustable, enhancing reliability.
In terms of durability, the KT3100T is expected to perform well with an electrical endurance rating of 10,000 cycles, which is typical for devices in the KT line. This feature reflects robustness against repeated operation in demanding environments, ensuring operational reliability.
