Product image is representative; revision or series may vary. Contact us to request a specific version.
LD3600
The LD3600 from Eaton Cutler-Hammer is a molded case circuit breaker designed for enhanced electrical performance. It supports a rated current of 600 A and is rated for operation at 600 V AC and 250 V DC.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for LD3600
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Series C Circuit Breakers |
| Part Number | LD3600 |
| Weight | 16.00 lbs (7.26 kg) |
| UPC | 786679341827 |
| Trip Type | T186 Trip |
| Rated Voltage (AC) | 600 V AC |
| Rated Voltage (DC) | 250 V DC |
| Terminal Type | Line and Load Connection |
| Frame Size | L Frame |
| Min. Frequency | 50 Hz |
| Max. Frequency | 60 Hz |
| Terminal Material | Aluminum |
| Number of Poles | 3 poles |
| Rated Current | 600 A |
The Eaton Cutler-Hammer LD3600 is a molded case circuit breaker, part of the Series C circuit breakers. This unit operates efficiently with a rated current capacity of 600 A. It functions effectively at a rated voltage of 600 V AC and 250 V DC, making it suitable for multiple applications in both AC and DC circuits. The circuit breaker utilizes a T186 trip mechanism which provides reliable fault protection.
Constructed with an L frame size, the LD3600 can accommodate various installation requirements. It features three poles designed for ensuring balanced load distribution across circuits. Terminal connections are constructed from aluminum, facilitating effective current transmission. The unit is designed for line and load connections, supporting versatile wiring configurations.
Operating within frequency limits ranging from 50 Hz to 60 Hz, the LD3600 is capable of adapting to different system requirements. This molded case circuit breaker is ideal for safeguarding electrical systems, ensuring safe and efficient operation across various environments.
