Product image is representative; revision or series may vary. Contact us to request a specific version.
UVH1LP03K
The Eaton Cutler-Hammer UVH1LP03K is a molded case circuit breaker designed for effective performance in electrical systems. Rated for a maximum of 225 amperes, this unit operates at a voltage of 24 VAC, supporting various applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for UVH1LP03K
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Series C Circuit Breakers |
| Part Number | UVH1LP03K |
| UPC | 786679552902 |
| Rated Voltage | 24 VAC |
| Rated Current | 225 A |
| Mounting Type | Field Mounted, Left Pole |
| Frame Type | F Frame |
| Connection Type | Pigtail Leads |
| Min. Operating Temperature | 0°C |
| Max. Operating Temperature | 40°C |
| Min. Storage Temperature | 0°C |
| Max. Storage Temperature | 40°C |
| Storage Humidity | 80% (non-Condensing) |
| Operating Humidity | 80% (non-Condensing) |
| Installation altitude | 1000 MSL |
The UVH1LP03K model from Eaton Cutler-Hammer is a molded case circuit breaker crafted for durability and reliability in various environments. This unit operates with a rated current of 225 A, making it suitable for demanding electrical applications. It functions at an input voltage of 24 VAC, providing stable performance. Designed with F Frame specifications, it features a connection method using pigtail leads for straightforward integration into existing setups.
For mounting, the circuit breaker is configured for field installation on the left pole, ensuring secure placement in various setups. The UVH1LP03K maintains operational efficacy within a temperature range that spans from 0°C to 40°C, enhancing its versatility across different climatic conditions. Additionally, the device's minimum and maximum storage temperatures echo the same range, from 0°C to 40°C, ensuring consistent performance during non-operational states.
With the ability to function in environments with humidity levels reaching 80% without condensation, this breaker also caters to specific installation requirements, accommodating altitudes up to 1000 meters above sea level. The UPC for this product is 786679552902, which aids in identification and inventory management.
