JGE3090FAG
The JGE3090FAG model from Eaton Cutler-Hammer is a molded case circuit breaker providing reliable circuit protection. This device operates effectively with an amperage rating of 90 A and is designed for both AC and DC applications with voltage ratings of 600 VAC and 250 VDC respectively.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for JGE3090FAG
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Series G Circuit Breakers |
| Part Number | JGE3090FAG |
| UPC | 782113962504 |
| Frame Type | JG Frame Type |
| Number of Poles | 3 Poles |
| Terminals | Line and Load |
| Rated Maximum Operating Frequency | 60 Hz |
| Rated Minimum Operating Frequency | 50 Hz |
| Amperage Rating | 90 A |
| AC Voltage Rating | 600 VAC |
| DC Voltage Rating | 250 VDC |
| Trip Type | T185 (Fixed Thermal, Adjustable Magnetic) |
| Interrupt Rating at 240 VAC | 65 kAIC |
| Interrupt Rating at 480 VAC | 25 kAIC |
| Interrupt Rating at 600 VAC | 18 kAIC |
The Eaton Cutler-Hammer JGE3090FAG serves as a molded case circuit breaker suitable for various applications. Designed within the robust JG frame type, this unit includes three poles to manage electrical circuits effectively. Rated for a maximum of 90 amps, the device can handle both 600 volts AC and 250 volts DC.
The breaker is equipped with a T185 trip type, which combines fixed thermal settings with adjustable magnetic capabilities, ensuring precise fault response. This model has notable interrupt ratings: 65 kAIC at 240 VAC, 25 kAIC at 480 VAC, and 18 kAIC at 600 VAC. With operational frequencies ranging from 50 Hz to 60 Hz, the JGE3090FAG offers flexibility across diverse electrical systems. It is equipped with both line and load terminals to facilitate easy installation and integration into existing setups. This circuit breaker is essential for maintaining system integrity and safety in a variety of applications.
