LGE3400FAG
The LGE3400FAG from Eaton Cutler-Hammer is part of the Series G Circuit Breakers, providing dependable performance in critical applications. Rated for 400 Amps, it operates in three-phase configurations with a maximum AC voltage of 600 VAC and DC voltage of 250 VDC.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for LGE3400FAG
| Manufacturer | Eaton Cutler-Hammer |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Series G Circuit Breakers |
| Part Number | LGE3400FAG |
| Weight | 16.00 lbs (7.26 kg) |
| UPC | 782116142408 |
| Frame Type | LG Frame |
| Current Rating | 400 A |
| Number of Poles | 3 Poles |
| Phase Type | Three-Phase |
| Max. Voltage (AC) | 600 VAC |
| Voltage Rating (DC) | 250 VDC |
| Frequency Rating | 50/60 Hz |
| Trip Technology | Thermal-Magnetic |
| Thermal Trip | Fixed |
| Magnetic Trip | Adjustable |
| Interrupt Rating @ 240 VAC | 65 kAIC |
| Interrupt Rating @ 480 VAC | 35 kAIC |
The Eaton Cutler-Hammer LGE3400FAG is designed as a molded case circuit breaker for robust electrical applications. With a current rating of 400 Amps, it accommodates three-phase systems efficiently. Its maximum allowable voltage stands at 600 VAC for alternating current and 250 VDC for direct current, ensuring versatility in various environments.
Weighing 16 lbs, this unit is structured within an LG frame type, which is known for its strength and modular design. This breaker is rated for operation at a frequency of 50/60 Hz, making it suitable for diverse industrial scenarios.
The LGE3400FAG employs thermal-magnetic trip technology, featuring a fixed thermal trip to prevent long-term overloads and an adjustable magnetic trip for immediate current surge protection. It possesses significant interrupt ratings, with the capacity to handle fault conditions of 65 kAIC at 240 VAC and 35 kAIC at 480 VAC. Overall, this circuit breaker is engineered to provide reliable protection and performance across a range of demanding applications.
