FANUC A02B A02B-0166-B001

Product image is representative; revision or series may vary. Contact us to request a specific version.

A02B-0166-B001

|
Need a Specific Revision?

The FANUC A02B-0166-B001 Power Mate Controller functions as a servo add-on module designed for precise control. Rated for an operating voltage of 24 VDC, it supports a current capacity of 5 A while maintaining a weight of 1.792 kg (3.95 lbs.).

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A02B-0166-B001

ManufacturerFANUC
Product LineA02B
Part NumberA02B-0166-B001
Weight4.00 lbs (1.81 kg)
ProductPower Mate Controller
PurposeServo Add-on Module
Operating Voltage24 VDC
Current Rating5A
Maximum Ambient Storage Temperature60°C
Altitude2000m
EnvironmentNo Corrosive Gases
Relative Humidity95% or less (non-condensing)
Minimum Ambient Operating Temperature0°C
Maximum Ambient Operating Temperature55°C
Minimum Ambient Storage Temperature-20°C
Request a Repair

The A02B-0166-B001 controller model from FANUC represents a power mate controller that functions as a servo add-on module. This module operates on a 24 VDC voltage and is capable of handling up to 5 A of current. The weight of this unit is 3.95 lbs., equivalent to 1.792 kg, making it manageable for installation in various systems.

For operational scenarios, this controller is rated to operate in environments with temperatures ranging from a minimum of 0°C to a maximum of 55°C. In terms of storage, it can be maintained in conditions ranging from -20°C to 60°C. It is engineered to perform well at altitudes of up to 2000 meters, ensuring versatility in various applications.

The A02B-0166-B001 is designed for environments free from corrosive gases, which helps maintain its reliability and longevity. Additionally, it has been designed to function efficiently in relative humidity levels of up to 95% as long as the atmosphere remains non-condensing, ensuring suitable performance in various climate conditions.
