FANUC A03B A03B-0807-C106

Product image is representative; revision or series may vary. Contact us to request a specific version.

A03B-0807-C106

|
Need a Specific Revision?

The FANUC A03B-0807-C106 is a compact input module designed for reliable digital DC input tasks. With 32 points, it operates efficiently at a voltage of 24 VDC, allowing for seamless integration in various control applications.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A03B-0807-C106

ManufacturerFANUC
Product TypeInput Module
Product LineA03B
Part NumberA03B-0807-C106
Weight0.56 lbs (0.26 kg)
Module TypeI/O Module Digital DC Input
Operating Voltage24 VDC
Input Current per Point3.0 mA
Number of Points32 Points
Input Voltage Range20-28 VDC
Signal Level0-24 VDC
Input TypeDC Digital Input
Mounting TypeDIN Rail
Request a Repair

FANUC provides the A03B-0807-C106 as a digital input module that specializes in managing DC input signals. Weighing in at just 0.23 kg, it enables efficient weight management within control panels. This module is engineered to support 32 individual input points, making it ideal for setups that require multiple connections. The operational voltage is set at 24 VDC, and the input current stands at 3.0 mA per point.

The input voltage range for the A03B-0807-C106 spans from 20 to 28 VDC, ensuring flexibility in various applications. Each input effectively handles signal levels between 0 to 24 VDC, affirming its capability for digital input scenarios. The design also accommodates DIN rail mounting, facilitating straightforward installation and organization within electrical cabinets, and providing a structured and efficient solution for control systems.
