FANUC A03B A03B-0807-C107

Product image is representative; revision or series may vary. Contact us to request a specific version.

A03B-0807-C107

|
Need a Specific Revision?

The FANUC A03B-0807-C107 16PT AC Input Module operates across a voltage range of 85 to 264V AC. This module is capable of detecting AC voltage signals of 24V or 110V and accommodates 16 input channels.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A03B-0807-C107

ManufacturerFANUC
Product LineA03B
Part NumberA03B-0807-C107
Weight0.69 lbs (0.31 kg)
Name16PT AC Input Module
Input Voltage85-264V AC
Input Signal TypeAC voltage signals 24V or 110V AC
Number of Input Points16 input channels (16 points)
Input Current5-10mA
Input Impedance20 kΩ
I/O Voltage24V AC or 110V AC
Response Time1ms
Protection ClassIP20
Connector TypeTerminal block
Operating Temperature Range0°C to 55°C
Mounting TypeRack-mountable
Power Consumption10W
IndicatorsStatus LEDs
Request a Repair

The FANUC A03B-0807-C107 16PT AC Input Module is designed to accept input voltages within the range of 85-264V AC. It handles AC voltage signals, specifically at 24V or 110V, and provides 16 input points. Each input channel requires an input current between 5 and 10 mA, with an input impedance measuring 20 kΩ.

This module features a quick response time of 1 millisecond, ensuring swift signal processing. It utilizes a terminal block connector for reliable connections to other components. With a power consumption of 10 watts, the module is efficient despite its advanced functionalities. Additionally, it is equipped with status LEDs that provide visual feedback of operating conditions.

Built for durability, the A03B-0807-C107 boasts a thermal operating range from 0°C to 55°C and is classified under protection class IP20. It is also designed for rack-mount installation, simplifying integration into existing setups. The overall dimensions of this input module are 160 mm in width, 120 mm in height, and 30 mm in depth, making it compact yet effective for various industrial applications.
