FANUC A03B A03B-0807-C155

Product image is representative; revision or series may vary. Contact us to request a specific version.

A03B-0807-C155

|
Need a Specific Revision?

The FANUC A03B-0807-C155 is a DC output module with 32 digital outputs. It operates at an output voltage of 12 V DC and delivers a maximum current of 16 A, making it suitable for a wide range of applications.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A03B-0807-C155

ManufacturerFANUC
Product LineA03B
Part NumberA03B-0807-C155
Weight0.56 lbs (0.26 kg)
NameDC Output Module
Output Points32 digital outputs
Output Voltage12 V DC
Output CurrentEach point rated for 0.5 A
Total Output Current16 A
Output TypeTransistor (NPN)
Mounting TypeDIN rail mountable
Operating Temperature Range0°C to 55°C
Storage Temperature Range-20°C to 70°C
HumidityUp to 90% RH, non-condensing
Protection ClassIP20
ComplianceCE marked, RoHS compliant
Connection TypeScrew terminal blocks
Status IndicatorsLED indicators
IsolationOptical isolation
Request a Repair

The A03B-0807-C155 from FANUC is a DC output module, specifically designed for automation systems requiring reliable digital control. It features a total of 32 digital outputs, operating at a 12 V DC voltage level. Each output point is rated to handle up to 0.5 A, allowing for a maximum cumulative output current of 16 A, which is suitable for a wide range of applications.

This output module utilizes an NPN transistor output type, ensuring effective and efficient switching capabilities. Users will appreciate its DIN rail mountable design, allowing for simple installation within enclosures. Designed to operate comfortably across an ambient temperature spectrum from 0°C to 55°C, it also supports a wider storage temperature range of -20°C to 70°C, allowing for flexible deployment in diverse environments.

With a humidity tolerance up to 90% RH without the risk of condensation, the A03B-0807-C155 can function in moderately humid conditions. It's classified with an IP20 rating, providing basic protection against solid objects larger than 12.5 mm. The module complies with CE and RoHS regulations, underscoring its suitability for global standards.

Connection is facilitated through screw terminal blocks, offering secure and stable wiring options. Additionally, it incorporates LED indicators for status monitoring, allowing users to quickly assess operational conditions. The device also features optical isolation, enhancing the protection of connected circuits from voltage spikes and noise interference.
