FANUC A03B A03B-0819-C052

Product image is representative; revision or series may vary. Contact us to request a specific version.

A03B-0819-C052

|
Need a Specific Revision?

The FANUC A03B-0819-C052 is a two-channel module designed for sequential relay control with advanced data handling capabilities. It operates with a voltage output range of -10 VDC to +10 VDC and a current output range of 0 mADC to +20 mADC.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A03B-0819-C052

ManufacturerFANUC
Product LineA03B
Part NumberA03B-0819-C052
Weight0.81 lbs (0.37 kg)
Resolution12-bits
Channels2 channels
Terminal BlockIncluded
ApplicationSequential relay control
CapabilitiesAdvanced data handling
Analog Output Range (Voltage)-10 VDC to +10 VDC
Analog Output Range (Current)0 mADC to +20 mADC
Voltage Resolution5 mV
Current Resolution20 µA
Operating Temperature0 to 45°C
Storage Temperature-20 to 60°C
Vibration≤0.5G
Humidity≤75%
Accuracy Voltage Output±0.5%
Request a Repair

The A03B-0819-C052 module by FANUC serves as a versatile two-channel module suited for tasks involving sequential relay control. With its 12-bit resolution, this module efficiently processes data, making it ideal for applications that require advanced data management. The analog outputs accommodate both voltage and current ranges, providing flexibility with outputs spanning from -10 VDC to +10 VDC for voltage and from 0 mADC to +20 mADC for current. Each channel’s resolution is also notable, offering 5 mV for voltage and 20 µA for current, enhancing the precision of its control capabilities.

Weighing in at just 0.36 kg, the device is manageable and easy to install, while its compact design does not compromise function. Conditions for operation fall between 0 to 45 degrees Celsius, with storage temperatures permissible from -20 to 60 degrees Celsius. The A03B-0819-C052 maintains reliable performance even under vibration levels of 0.5G or less and is designed to function effectively in environments with humidity below 75%. Finally, it ensures accuracy within ±0.5% for voltage output, rounding out its profile as a dependable and efficient module for industrial applications.
