FANUC A06B A06B-0212-B805

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-0212-B805

|
Need a Specific Revision?

The FANUC A06B-0212-B805 is a robust servo motor equipped with advanced features for high-speed applications. It is capable of delivering a rated operational speed of 5000 RPM, making it suitable for precise motion control in CNC systems.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-0212-B805

ManufacturerFANUC
Product LineA06B
Part NumberA06B-0212-B805
Weight9.00 lbs (4.08 kg)
Motor TypeServo Motor
BrakeIntegrated Brake
EncoderA64IA Encoder
Torque2 Nm
Rated Speed5000 RPM
ShaftStraight
KeywayIncluded
Operating Temperature-10 to 40 degrees Celsius
Maximum Vibration5G
Maximum Altitude1000 Meters Above Sea Level
CNC ApplicationsSupported
Request a Repair

The FANUC A06B-0212-B805 servo motor is distinguished by its reliable performance and capability to support demanding applications. It features an integrated brake for improved safety and control during operation. This model boasts an encoder type labeled A64IA, which provides precise feedback for enhanced positioning accuracy.

Engineered to deliver a torque of 2 Nm, this motor is designed for high-speed operations with a rated speed of 5000 RPM. The straight shaft with an included keyway ensures compatibility with various mechanical setups. The A06B-0212-B805 operates effectively within an environmental range of -10 to 40 degrees Celsius, making it adaptable for multiple settings.

Additionally, it can tolerate vibrational stress of up to 5G without compromising performance, and it maintains functionality at altitudes of 1000 meters above sea level. This makes it particularly valuable for CNC applications where high precision and reliability are essential.
