FANUC A06B A06B-6088-H226#H500

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6088-H226#H500

|
Need a Specific Revision?

The FANUC A06B-6088-H226#H500 is a spindle amplifier designed for CNC systems. It operates effectively in conditions with an ambient temperature ranging from 0°C to 55°C and can deliver a rated output current of 63 amps.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6088-H226#H500

ManufacturerFANUC
Product TypeSpindle Amplifier (Spindle Drive)
Product LineA06B
Part NumberA06B-6088-H226#H500
Weight30.00 lbs (13.61 kg)
ApplicationCNC Systems
Cooling MethodAir Cooled
Operating Temperature0°C to 55°C
MountingVertical/Wall-mounted
Rated Output Current63 A
Input Phase3 Phase
Frequency50/60 Hz
Rated Input Voltage200-230 V
Protection FeaturesOverload, Overcurrent, Overvoltage Protection
Rated Output Voltage230 V
Request a Repair

The A06B-6088-H226#H500 spindle amplifier from FANUC is specifically engineered for CNC systems. This device operates effectively within a temperature range of 0°C to 55°C and is designed for vertical or wall-mounted installation, enabling flexibility in application environments. The A06B-6088-H226#H500 spindle amplifier can handle three-phase electrical input, with a rated voltage between 200 to 230 V, ensuring compatibility with various setups.

It delivers a substantial output current rating of 63 amperes, which supports robust spindle operations. The cooling mechanism is air-cooled, promoting efficiency by maintaining appropriate operational temperatures inside the unit. The amplifier weighs 11.00 kg, which facilitates installation and support.

The A06B-6088-H226#H500 also integrates several protection features to enhance reliability, including overload, overcurrent, and overvoltage protection. Its operational frequency accommodates both 50 Hz and 60 Hz applications, making it versatile for diverse CNC tasks. Overall, this spindle drive is essential for controlling spindle performance in CNC machinery.
