A06B-6093-H102
The FANUC A06B-6093-H102 is a servo amplifier tailored for CNC systems, ensuring precise motion control. At 1.81 kg, this model operates on input voltages between 220 and 240 VAC and functions effectively within a frequency range of 50/60 Hz.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for A06B-6093-H102
| Manufacturer | FANUC |
|---|---|
| Product Type | Servo Amplifier (Servo Drive) |
| Product Line | A06B |
| Part Number | A06B-6093-H102 |
| Weight | 7.00 lbs (3.18 kg) |
| Application | CNC Systems |
| Frequency | 50/60 Hz |
| PWM Interface Type | BETA PWM Interface |
| Operating Temperature | 0°C to 55°C |
| Protection Features | Overload, Overcurrent Protection |
| Input Voltage | 220-240 VAC |
| Servo Unit Type | BETA SERVO UNIT TYPE SVU-20 |
| Mounting | Vertical/Wall-mounted |
| Cooling Method | Air Cooled |
The A06B-6093-H102 from FANUC serves as a critical component in CNC systems, functioning as a servo amplifier or servo drive. This unit is engineered for robustness, accommodating a 220 to 240 VAC input voltage range. It efficiently operates at frequencies of either 50 or 60 Hz.
Weighing in at 1.81 kg, this servo amplifier is designed to maintain stable operations within an ambient temperature scope of 0°C to 55°C. The design incorporates the BETA PWM interface and allows for flexible installation options, as it can be mounted vertically or on walls as needed. Additionally, air cooling is employed for temperature regulation during processes.
To enhance operational safety, the A06B-6093-H102 also includes several protection features. These encompass both overload and overcurrent safeguards, crucial for preventing damage during high-stress scenarios. Paired with the BETA SERVO UNIT TYPE SVU-20, this product is fully capable of ensuring precise control in automated and CNC applications.
