FANUC A06B A06B-6096-H106

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6096-H106

|
Need a Specific Revision?

The FANUC A06B-6096-H106 is a servo amplifier designed for single-axis applications. It delivers a rated power of 9.1 kW and operates with an output voltage of 230 volts.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6096-H106

ManufacturerFANUC
Product TypeServo Amplifier
Product LineA06B
Part NumberA06B-6096-H106
Weight13.00 lbs (5.90 kg)
Number of Axes1 Axis
Rated Power9.1 kW
Output Voltage230V
CNC ApplicationsSupported
Operating Temperature0 to 40 degrees Celsius
Maximum Vibration5G
Maximum Altitude1000 Meters Above Sea Level
Approximate Dimensions11.9 x 14 x 3.3 Inches
Input Voltage283-325V
Request a Repair

The A06B-6096-H106 model from FANUC operates as a highly efficient servo amplifier, specifically designed for single-axis functionality. This unit has a rated output power of 9.1 kW, suitable for various automation requirements. The output voltage is set at 230 volts, supporting numerous applications.

The servo amplifier requires a supply ranging from 283 to 325 volts in terms of voltage input. Its weight is around 13.5 pounds, which promotes a manageable installation process. Its dimensions, measuring 11.9 x 14 x 3.3 inches, ensure that it can fit into standard equipment environments. The operating temperature for this amplifier lies between 0 and 40 degrees Celsius, which broadens its versatility for use in different settings.

This servo amplifier can also withstand a maximum vibration level of 5G, making it resilient to dynamic conditions within a working environment. Furthermore, it can operate effectively at altitudes up to 1000 meters above sea level, ensuring consistent performance in various locations. Designed with CNC applications in mind, it represents a solid option for precise motion control tasks.
