FANUC A06B A06B-6096-H305

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6096-H305

|
Need a Specific Revision?

The FANUC A06B-6096-H305 is a three-axis servo amplifier with a robust power output of 3.1 kW. This unit functions effectively in temperatures ranging from 0 to 40 degrees Celsius and can handle an altitude of up to 1000 meters.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6096-H305

ManufacturerFANUC
Product LineA06B
Part NumberA06B-6096-H305
Weight19.00 lbs (8.62 kg)
ProductServo Amplifier
Number of Axes3 Axes
Power Rating3.1 kW
Operating Temperature0 to 40 degrees Celsius
Maximum Vibration5G
Maximum Altitude1000 Meters Above Sea Level
Input Voltage283-325V
Output Voltage230V Maximum
L-Axis Output Current3 Amps
M-Axis Output Current3 Amps
N-Axis Output Current12.5 Amps
CNC ApplicationsSupported
Request a Repair

The FANUC A06B-6096-H305, classified as a servo amplifier, supports up to three axes, making it suitable for complex machining tasks. It offers a power rating of 3.1 kW, ensuring robust performance for demanding applications. Designed to operate in temperatures ranging from 0 to 40 degrees Celsius, this unit remains effective in various conditions.

This amplifier can withstand a maximum altitude of 1000 meters above sea level and is built to endure vibrations of up to 5G. Efficiently powered by an input voltage of 283 to 325 volts, it also delivers a maximum output voltage of 230 volts. The output current specifications include 3 amps for both the L and M axes, while the N axis is rated for 12.5 amps, allowing for flexibility in motion control.

The A06B-6096-H305 is well-suited for CNC applications and is engineered to provide stability and efficiency in various industrial setups. Its design enables reliable operation in scenarios where precision and control are critical.
