FANUC A06B A06B-6114-H103

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6114-H103

|
Need a Specific Revision?

The A06B-6114-H103 is a servo amplifier module from FANUC's A06B series designed to efficiently handle operations. This unit operates from 0°C to 55°C while maintaining functionality under specified humidity levels.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6114-H103

ManufacturerFANUC
Product LineA06B
Part NumberA06B-6114-H103
Weight11.00 lbs (4.99 kg)
Name of ModuleServo Amplifier Module
Ambient Humidity90% RH or less (No condensation)
Max. Ambient Operating Temp.55°C
Output Voltage200-240 VAC
Min. Ambient Operating Temp.0°C
Rated Output Current6.5A
Output Frequency Range0.1 - 800 Hz
Input Voltage283-339 VDC
Rated Input Power2.5 kW
Input Frequency50/60 Hz
Request a Repair

The A06B-6114-H103 servo amplifier module from FANUC is engineered for superior performance in automation systems. It operates within a minimum ambient temperature of 0°C and can withstand maximum conditions of 55°C. The A06B-6114-H103 module is designed to ensure stable operation in environments with humidity levels up to 90% relative humidity, as long as no condensation is present.

With a specified output voltage ranging from 200 to 240 VAC, the A06B-6114-H103 module adapts to different scenarios. The output frequency spans from 0.1 Hz to 800 Hz, providing versatility for varying speed requirements. Current output ratings reach up to 6.5A, ensuring reliable motor operation. For optimal performance, the A06B-6114-H103 requires an input voltage between 283 and 339 VDC and has a rated input power requirement of 2.5 kW. The input frequency can be supported at both 50 Hz and 60 Hz, enhancing the module’s compatibility with various electrical systems.
