FANUC A06B A06B-6114-H209

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6114-H209

|
Need a Specific Revision?

The FANUC A06B-6114-H209 servo amplifier module is designed for precision control in servo applications. With a robust input voltage range and rated power, it efficiently manages output for demanding tasks.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6114-H209

ManufacturerFANUC
Product LineA06B
Part NumberA06B-6114-H209
Weight15.00 lbs (6.80 kg)
Product DescriptionServo Amplifier Module
Output Frequency Range0.1 - 800 Hz
Input Voltage283-339 VDC
Rated Input Power11 kW
Input Frequency50/60 Hz
Ambient Humidity90% RH or less (No condensation)
Max. Ambient Operating Temp.55°C
Output Voltage200-240 VAC
Min. Ambient Operating Temp.0°C
Rated Output Current19A (L-axis), 19A (M-axis)
Request a Repair

Functional versatility defines the FANUC A06B-6114-H209 servo amplifier module. Designed for applications requiring precise control, this module operates with an input voltage of 283 to 339 VDC, ensuring compatibility with various systems. It harnesses a rated input power of 11 kW to deliver reliable performance.

Users can expect an output frequency range from 0.1 to 800 Hz, enabling fine adjustments in speed and control. Regarding output, the A06B-6114-H209 module's voltage levels range from 200 to 240 VAC, catering to the requirements of different servo-driven applications.

The A06B-6114-H209 servo motor ensures safe operation with a rated output current of 19A for both the L and M axes. Operating conditions are critical, and this module is designed to withstand ambient temperatures between 0°C and 55°C. Moreover, it can function effectively in ambient humidity levels of 90% RH or lower, provided no condensation occurs. Overall, this module is tailored for those who require efficient and robust servo amplification solutions.
