FANUC A06B A06B-6117-H103

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6117-H103

|
Need a Specific Revision?

The A06B-6117-H103 is a servo amplifier module from FANUC designed for specific operational requirements. This model supports an output frequency range from 0.1 to 800 Hz and operates with a rated output current of 6.5 A on the L-axis.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6117-H103

ManufacturerFANUC
Product LineA06B
Part NumberA06B-6117-H103
Weight11.00 lbs (4.99 kg)
DescriptionServo Amplifier Module
Rated Output Current6.5 A (L-axis)
Output Frequency Range0.1 - 800 Hz
Input Voltage283-339 VDC
Rated Input Power2.5 kW
Input Frequency50/60 Hz
Min. Ambient Operating Temp.0°C
Max. Ambient Operating Temp.55°C
Output Voltage200-240 VAC
Ambient Humidity90% RH or less (No condensation)
Request a Repair

FANUC's A06B-6117-H103 is a specialized servo amplifier module with capabilities tailored for dynamic control tasks. It is engineered to provide an output frequency range from 0.1 Hz up to 800 Hz, making it versatile for various applications. The rated output current is 6.5 A for the L-axis, ensuring suitable power delivery for demanding operations.

This efficient and reliable module operates within an input voltage range of 283 VDC to 339 VDC and delivers a rated input power of 2.5 kW. It is compatible with both 50 Hz and 60 Hz input frequencies, enabling flexibility in diverse power supply conditions.

The A06B-6117-H103 servo amplifier is built to withstand environmental fluctuations. It functions effectively at ambient temperatures ranging from 0°C to 55°C, providing a wide operational threshold. Additionally, it can operate in environments with humidity levels up to 90% RH as long as condensation does not occur. The output voltage ranges from 200 to 240 VAC, enhancing its adaptability across applications.
