FANUC A06B A06B-6140-H011

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6140-H011

|
Need a Specific Revision?

The A06B-6140-H011 is a dedicated servo amplifier module manufactured by FANUC. It offers robust performance with specific input and output voltage requirements and is designed for precise motion control tasks.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6140-H011

ManufacturerFANUC
Product LineA06B
Part NumberA06B-6140-H011
Weight11.00 lbs (4.99 kg)
Name of ModuleServo Amplifier Module
Input Frequency50/60 Hz
Voltage Phase3-phase
Rated Output Voltage Range283 to 339V
Rated Output Current13.2 kW
Height38 cm
Width9 cm
Length27.2 cm
Voltage Class200V
Rated Input Voltage200 to 240 VAC
Main Input Current49 A
Request a Repair

The FANUC A06B-6140-H011 module is specifically designed as a servo amplifier, focusing on delivering high performance in varying applications. It accommodates a 3-phase power supply and functions effectively at 50 or 60 Hz input frequencies, offering flexibility for different operational settings.

This servo amplifier module boasts a rated output voltage adaptability ranging from 283 to 339 volts while supporting an output current rated at 13.2 kW. These specifications make it suitable for intricate control tasks that demand reliability.

In terms of dimensions, the A06B-6140-H011 module measures 38 cm in height, 9 cm in width, and 27.2 cm in length. With a total weight of 6.3 kg, it remains manageable for installation. The A06B-6140-H011 operates under a voltage class of 200V and is designed for input voltages spanning 200 to 240 VAC. Its main input current reaches up to 49 A, ensuring sufficient power for comprehensive functionality. Overall, this servo amplifier module effectively solves precision motion control applications.
