FANUC A06B A06B-6240-H210

Product image is representative; revision or series may vary. Contact us to request a specific version.

A06B-6240-H210

|
Need a Specific Revision?

The A06B-6240-H210 from FANUC is a dual-axis servo amplifier module optimized for precise motion control. It operates with a rated voltage of 200 V AC, supporting an output voltage of 240 V across a three-phase system.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A06B-6240-H210

ManufacturerFANUC
Product TypeServo Amplifier Module
Product LineA06B
Part NumberA06B-6240-H210
Weight12.00 lbs (5.44 kg)
Rated Voltage200 V
Voltage TypeAC
Output Voltage240 V AC
Number Of Phase3-Phase
Rated Current (L-axis)22.5 A
Rated Current (M-axis)45 A
Min. Output Frequency0 Hz
Max. Output Frequency550 Hz
Mounting TypePanel Mounted
Axis ConfigurationDual-axis
Request a Repair

The A06B-6240-H210 servo amplifier module by FANUC is engineered for dual-axis applications, enhancing the control of motion systems. Operating with an input voltage rating of 200 V AC, this unit is designed to handle an output voltage of 240 V AC effectively. It operates within a three-phase system, facilitating increased performance and efficiency during operations.

This module is capable of accepting output frequencies ranging from 0 Hz up to a maximum of 550 Hz, allowing it to adapt to varying application demands. The design focuses on providing robust current ratings, offering 22.5 A for the L-axis and 45 A for the M-axis, making it suitable for various servo-controlled tasks.

For installation, the A06B-6240-H210 is panel mounted, ensuring a secure and stable setup within control cabinets. This integration allows for optimal placement in machinery or automation setups, streamlining operation and reducing wiring complexity. Overall, the FANUC A06B-6240-H210 module represents a solid choice for applications requiring dual-axis control in industrial environments.
