FANUC RJ3iB EE-3505-740-001

Product image is representative; revision or series may vary. Contact us to request a specific version.

EE-3505-740-001

|
Need a Specific Revision?

The FANUC EE-3505-740-001 is an encoder and brake module from the RJ3iB series, designed specifically for robotic applications. Weighing approximately 1.5 kg, it is optimized to support 6-axis systems and typically operates with a 24V DC power supply.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for EE-3505-740-001

ManufacturerFANUC
Product TypeEncoder/Brake Module
Product LineRJ3iB
Part NumberEE-3505-740-001
Weight2.00 lbs (0.91 kg)
Mounting TypeModular Mounting
ApplicationRobotics
Number of Axes6 Axes
Power SupplyTypically DC (24V)
FunctionEncoder and Brake Control
InterfaceDigital Signal Interface
CompatibilityCompatible with Multi-Axis Robotics Systems
Operating Temperature-10°C to +60°C
Protection ClassIP20 (for indoor use)
Request a Repair

The FANUC EE-3505-740-001 module is integral to advanced robotics functionality, acting as both an encoder and brake control system. Specifically crafted for multi-axis robotics applications, this component enables precise control over six axes. The device boasts a modular mounting type, facilitating straightforward installation while maintaining a compact design that weighs around 1.5 kg.

Typically powered by a 24V DC supply, the encoder and brake module communicates via a digital signal interface. Operating efficiently within a temperature spectrum of -10°C to +60°C, it ensures consistent performance across a variety of environments. Designed for indoor use, it holds an IP20 protection class rating, emphasizing its suitability for secure installations.

The compatibility of the EE-3505-740-001 module with multi-axis robotics systems makes it an essential component for high-performance automation setups. Its capabilities ensure it meets the demands of contemporary robotic applications, providing smooth and reliable encoder and brake control.
