FANUC RJ3iB EE-3505-761-001

Product image is representative; revision or series may vary. Contact us to request a specific version.

EE-3505-761-001

|
Need a Specific Revision?

The EE-3505-761-001 by FANUC is an encoder brake module designed to function within the RJ3iB series. It operates effectively at a rated voltage of 200 to 240 volts AC and can handle an input ranging from 180 to 264 volts AC. This module supports a continuous power rating of 5 kW and has a peak power capability of 7.5 kW.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for EE-3505-761-001

ManufacturerFANUC
Product TypeEncoder Brake Module
Product LineRJ3iB
Part NumberEE-3505-761-001
Weight2.19 lbs (0.99 kg)
Rated Voltage200-240V AC
Operating Voltage Range180-264V AC
Rated Power5 kW
Peak Power7.5 kW
Rated Current25A
Peak Current37.5A
Resistance Value10 ohms ±5%
Breaking TorqueUp to 150%
Duty Cycle10-40%
Cooling MethodForced Air Cooling
Protection ClassIP20
Operating Temperature0°C to 50°C
Storage Temperature-20°C to 70°C
Axes7 Axes
Request a Repair

The FANUC EE-3505-761-001 encoder brake module is engineered for advanced automation systems, specifically within the RJ3iB series. This device functions at a rated voltage of 200 to 240 volts AC, while the operational voltage can vary from 180 to 264 volts AC. With a rated power of 5 kW and a peak power of 7.5 kW, the module excels in demanding applications.

It is capable of handling a rated current of 25A, while its peak current reaches 37.5A. Furthermore, the resistance value of the module is specified at 10 ohms ±5%. The breaking torque can be maximally rated up to 150%, providing enhanced performance in deceleration and stopping scenarios. The duty cycle is rated between 10% and 40%, indicating optimal operational efficiency.

Cooling is managed by a forced air method, ensuring the module operates within safe temperature limits. The protection class of IP20 indicates its suitability for various applications while ensuring adequate ingress protection. The operational temperature range is set between 0°C to 50°C, while it can endure a storage temperature of -20°C to 70°C. The module is designed for complex systems integrating 7 axes, making it a versatile component for various robotic functionalities.
