FANUC Series 20 A02B-0259-C221

Product image is representative; revision or series may vary. Contact us to request a specific version.

A02B-0259-C221

|
Need a Specific Revision?

The A02B-0259-C221 is a handheld operator panel from FANUC’s Series 20, featuring a 5.7-inch LCD with a resolution of 320 x 240 pixels. This device is designed for reliable operation in various conditions, supported by its IP65-rated enclosure.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for A02B-0259-C221

ManufacturerFANUC
Product LineSeries 20
Part NumberA02B-0259-C221
NameHandheld handy operator panel
Display TypeLCD (Liquid Crystal Display)
Display Size5.7 inches
Resolution320 x 240 pixels (QVGA)
Display ColorMonochrome (black and white)
BacklightLED backlight
Keypad TypeMembrane keypad with tactile feedback
Key LayoutAlphanumeric keys, function keys, and directional keys
Power Supply24 V DC
Power Consumption20W
Operating Temperature Range0°C to 40°C
Storage Temperature Range-20°C to 60°C
Humidity Range20% to 80% RH (non-condensing)
Enclosure RatingIP65
Request a Repair

The FANUC A02B-0259-C221 handheld handy operator panel provides user-friendly control in a compact design. Its 5.7-inch LCD with QVGA resolution delivers clear visual output in monochrome. The device features an efficient LED backlight for enhanced visibility in various lighting conditions. User input is facilitated through a membrane keypad that features tactile feedback, designed with an arrangement of alphanumeric, function, and directional keys.

This operator panel operates on a 24 V DC power supply, with a consumption of 20 watts, making it suitable for various applications. The operational temperature range is from 0°C to 40°C, providing versatile functionality in diverse environments. In contrast, it can be stored in temperatures from -20°C to 60°C. The device supports a humidity range of 20% to 80% relative humidity, non-condensing, ensuring stable performance even in varying moisture levels.

The enclosure is rated IP65, providing protection against dust and low-pressure water jets, enabling it to operate in harsher conditions. The dimensions of the panel are 210 mm in width, 150 mm in height, and 60 mm in depth, making it compact while still providing a functional interface for operators.
