Product image is representative; revision or series may vary. Contact us to request a specific version.
IC660TBR101
The IC660TBR101 terminal assembly from GE Fanuc Emerson is designed for efficiency in control systems. Capable of handling a voltage rating of both 115 and 230 VAC, it offers flexibility in electrical configurations. This unit supports 16 relay output circuits and includes a robust screw terminal box enclosure.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for IC660TBR101
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Terminal Assembly |
| Product Line | Genius I-O |
| Part Number | IC660TBR101 |
| Weight | 1.25 lbs (0.57 kg) |
| Enclosure Type | Screw Terminal Box |
| Circuit Configuration | 16 Relay Output Circuits |
| Voltage Rating | 115/230 VAC, Selectable |
| Block Current Draw | 87 mA @ 115 VAC |
| Field Wiring Range | 22-12 AWG Copper |
| Terminal Count | 32 Positions |
| Configuration Storage | EEPROM |
| Mounting Orientation | Vertical or Horizontal |
| Field Wiring Feature | Remove Block, Wiring Intact |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | -40 to 100 °C |
| Operating Humidity | 5 to 95 %, Non-Condensing |
The GE Fanuc Emerson IC660TBR101 is a terminal assembly specifically engineered to optimize control panel layouts and field wiring connectivity. This robust device features a screw terminal box that ensures reliable connection points while supporting circuit configurations of up to 16 relay outputs. Users can select between voltage ratings of 115 or 230 VAC, tailoring adjustments to suit the application environment.
Designed with versatility in mind, the IC660TBR101 allows for a maximum block current draw of 87 mA when operating at 115 VAC. The assembly is equipped with 32 positions for terminal connections, which supports a broad wiring range of 22 to 12 AWG copper, accommodating various wiring needs. Users will appreciate the capability to maintain field wiring intact while removing the terminal block, facilitating easier maintenance and troubleshooting.
The terminal assembly is suitable for mounting vertically or horizontally, providing options based on installation requirements. Operating conditions for this device extend from 0 to 60 °C, with a storage temperature tolerance ranging from -40 to 100 °C. Additionally, it supports a moisture range of 5 to 95%, non-condensing, making it effective for diverse environmental applications. Configuration data is stored in EEPROM, allowing reliable retention of settings for ease of use.
| Revision Part # | Also known as | |
|---|---|---|
| IC660TBR101A | IC660TBR101-A, Series A, Rev A | |
| IC660TBR101B | IC660TBR101-B, Series B, Rev B | |
| IC660TBR101C | IC660TBR101-C, Series C, Rev C | |
| IC660TBR101K | IC660TBR101-K, Series K, Rev K | |
| IC660TBR101L | IC660TBR101-L, Series L, Rev L | |
| Don't see your particular revision? Contact us now. | ||
