Product image is representative; revision or series may vary. Contact us to request a specific version.
FBN36TE040RV
The FBN36TE040RV is a molded case circuit breaker from GE Fanuc Emerson's Record Plus series. Rated at 40 Amps and designed for a voltage of 600Y/347 VAC, it utilizes a thermal magnetic trip type for reliable performance.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for FBN36TE040RV
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Record Plus |
| Part Number | FBN36TE040RV |
| UPC | 783164395174 |
| Trip Type | Thermal Magnetic |
| Interrupting Capability | 65 kAIC nominal, 150 kAIC frame |
| Mounting Method | Panel Mounted |
| Operator Type | Pivot Toggle Handle |
| Phase | 3 Phase |
| Voltage Rating | 600Y/347 VAC |
| Rated Current | 40 Amps |
| Poles | 3 Poles |
| Conductor Range | 10 to 4 AWG |
| Frequency Compatibility | 50/60 Hz |
| Accessory Support | Aux, Shunt, UV Compatible |
| Connection Style | Load Lugs, AD Panel Interface |
The GE Fanuc Emerson FBN36TE040RV is a molded case circuit breaker used for various application needs. It operates at a rated current of 40 Amps, making it suitable for multiple electrical systems. The device supports a voltage rating of 600Y/347 VAC and is configured for three-phase operation.
This breaker utilizes thermal magnetic trip technology, promoting reliable tripping during overload or fault conditions. It features an interrupting capability of 65 kAIC under nominal conditions and can withstand a maximum frame interrupting capacity of up to 150 kAIC.
For installation, the device employs a panel-mounted design and allows for use with a pivot toggle handle for operator control. The conductor range supported by this model lies between 10 AWG to 4 AWG, ensuring compatibility with a variety of wiring standards.
Compatible with 50 and 60 Hz frequencies, the FBN36TE040RV also features provisions for auxiliary devices, shunt trips, and ultraviolet protection support. It has a connection style that accommodates load lugs and includes an AD panel interface for easy integration into existing electrical installations.
