FBN36TE090RV
The FBN36TE090RV from GE Fanuc Emerson is a molded case circuit breaker designed for reliable protection and operation in demanding conditions. With a rated operating voltage of 600 V and a current rating of 90 A, this device is suitable for three-phase applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for FBN36TE090RV
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Record Plus |
| Part Number | FBN36TE090RV |
| UPC | 783164395235 |
| Functions | LI - Long-Time and Instantaneous Trip |
| Protection Type | Thermal Magnetic |
| Connection Type | Bolt-On Connection |
| Interrupt Rating at 480 V | 65 KAIC |
| Phase Type | 3 Phase |
| Number of Poles | 3 Poles |
| Rated Voltage | 600 V |
| Rated Current | 90 A |
| Minimum Operating Temperature | 0°C |
| Maximum Operating Temperature | 40°C |
The GE Fanuc Emerson FBN36TE090RV is a molded case circuit breaker providing essential overload and short circuit protection primarily used in industrial settings. Designed within the Record Plus series, this breaker allows for a rated current of 90 A at a maximum voltage of 600 V. Its three-pole design makes it suitable for three-phase systems, helping to ensure efficient power management.
The protection mechanism utilizes thermal magnetic technology, enabling both long-time and instantaneous trip functions. This feature ensures timely response to electrical faults, thereby safeguarding connected equipment from potential damage. With an interrupt rating of 65 KAIC at 480 V, the FBN36TE090RV is capable of handling substantial fault currents, contributing to overall system reliability. The breaker incorporates a bolt-on connection type, which simplifies installation and enhances stability in the electrical configuration.
Moreover, the operating temperature range allows this device to function optimally between 0°C and 40°C, making it adaptable to a variety of environments. The UPC for this model is 783164395235, for ease of identification.
