Product image is representative; revision or series may vary. Contact us to request a specific version.
FBV36TE040RV
The FBV36TE040RV model from GE Fanuc Emerson in the Record Plus series is a molded case circuit breaker designed for versatility. This three-pole breaker can handle a rated current of 40 A and supports various system voltages including 240 VAC, 480 VAC, and 600/347 VAC.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for FBV36TE040RV
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Record Plus |
| Part Number | FBV36TE040RV |
| UPC | 783164395044 |
| Number of Poles | 3 Poles |
| Rated Current | 40 A |
| System Voltage | 240 VAC, 480 VAC, 600/347 VAC |
| Frame Type | FB 100 Frame |
| 240 VAC Interrupting Rating | 65 KAIC |
| 480 VAC Interrupting Rating | 35 KAIC |
| 600/347 VAC Interrupting Rating | 22 KAIC |
| Long Time | Fixed |
| Short Time | Fixed |
| Suitable for Reverse Feed | Yes |
| Wire Range | 10-4 AWG |
The GE Fanuc Emerson FBV36TE040RV is categorized as a molded case circuit breaker under the Record Plus series. This unit is equipped with three poles and is rated for a maximum current of 40 A. It is designed to operate effectively at various system voltages, namely 240 VAC, 480 VAC, and 600/347 VAC.
In terms of frame construction, it utilizes an FB 100 type design. The breaker is rated for significant interrupting capacities: 65 KAIC for 240 VAC, 35 KAIC for 480 VAC, and 22 KAIC for 600/347 VAC. The trip functions for long time and short time interruptions are both configured as fixed settings, providing consistent and reliable performance.
It can be used in reverse feed configurations, offering flexibility in installation. Wire connections can accommodate a range from 10 AWG to 4 AWG, allowing for various conductor sizes in usage. With the UPC of 783164395044, this molded case circuit breaker ensures compliance with necessary standards while delivering dependable protection in electrical systems.
