IC693ACC340

Description: The IC693ACC340 power supply is a redundant power supply system by GE Fanuc, and it is part of Series 90-30. This system has a 24 Volts DC user output rating, and it comes with a 0.125-meter cable.
Available Now
Request a quote for IC693ACC340

Description:

The IC693ACC340 power supply is a redundant power supply system by GE Fanuc, and it is part of Series 90-30. This system has a 24 Volts DC user output rating, and it comes with a 0.125-meter cable.


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for GE Fanuc.

top legal disclaimer
disclaimer
credit cards
better business bureau

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the IC693ACC340.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.7 with 6 reviews

    Technical Specifications for IC693ACC340

BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693ACC340
Cable Length 0.125 meters
Minimum Clearance4 millimeters
TypeRedundant power supply system
Compatible Components PLC
Output24 VDC
System Storage Temperature-40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
Backup Serial PortSupported
BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693ACC340
Cable Length 0.125 meters
Minimum Clearance4 millimeters
TypeRedundant power supply system
Compatible Components PLC
Output24 VDC
System Storage Temperature-40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
Backup Serial PortSupported
s

About IC693ACC340

The GE Fanuc IC693ACC340 power supply is a redundant power supply system which is part of GE Series 90-30. The baseplate of the GE Fanuc IC693ACC340 redundant power supply system comes with 2 slots for standard power supply units. In addition to that, it has an attached cable for adapter connections, which connects to the IC693ACC340 power supply system, 24 Volts DC of user output, LED lights for showing the supply module's status as well as the status of the relay outputs. Currently, there are 2 models of redundant power supply baseplates from GE Series 90-30. These plates are identical apart from the length of the connection cable. In  the case of the GE Fanuc IC693ACC340 redundant power supply baseplate, it comes with a 0.125-meter cable.







The IC693ACC340 redundant power supply system by GE Fanuc connects to a standard IC639 programmable logic controller (PLC) power supply slot in the baseplate. The system also comes with a connector that connects to the redundant power supply connection cable of the adapter. Additionally, the system comes equipped with a backup serial port and battery connector for the PLC. However, the backup serial port and battery connector are not functional when used on an individual power supply. The users must always observe the specified ventilation clearances when mounting the IC693ACC340 redundant power supply system. There must be a minimum of 4 millimeters of clearance on all the 4 sides of the baseplate. This distance helps in providing ample ventilation for the baseplate. When the baseplate is mounted on a vertical surface, with its length oriented horizontally, it achieves its full load rating at 60 degrees Celsius (140 degrees Fahrenheit). This mounting orientation allows for optimum ventilation for this power supply.



Repair Services for IC693ACC340

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC693ACC340. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.
