IC693MDL350

Revisions: AA
Description: The GE Fanuc IC693MDL350 module is an isolated output module manufactured as part of the GE Intelligent Platforms/GE Fanuc Series 90-30. This module operates on 120 to 240 volts AC voltage and it has 16 isolated output points.
In Stock Ships Today
Request a quote for IC693MDL350

Description:

The GE Fanuc IC693MDL350 module is an isolated output module manufactured as part of the GE Intelligent Platforms/GE Fanuc Series 90-30. This module operates on 120 to 240 volts AC voltage and it has 16 isolated output points.


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for GE Fanuc.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: AA

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the IC693MDL350.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.8 with 11 reviews

    Technical Specifications for IC693MDL350

BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693MDL350
BrandGE Intelligent Platforms/GE Fanuc
Product TypeOutput Module
Voltage Rating120 to 240 V AC
Output Voltage Range74 to 265 V AC
Frequency50 to 60 Hz
Nominal Output Voltage120 to 240 V AC
Outputs16
Field to Backplane Isolation250 V AC continuous; 1500 VAC for 1 minute
Group to Group Isolation250 V AC continuous; 1500 VAC for 1 minute
Max. Inrush Current per Cycle20 Amps
Minimum Load Current per Point10 mA
BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693MDL350
BrandGE Intelligent Platforms/GE Fanuc
Product TypeOutput Module
Voltage Rating120 to 240 V AC
Output Voltage Range74 to 265 V AC
Frequency50 to 60 Hz
Nominal Output Voltage120 to 240 V AC
Outputs16
Field to Backplane Isolation250 V AC continuous; 1500 VAC for 1 minute
Group to Group Isolation250 V AC continuous; 1500 VAC for 1 minute
Max. Inrush Current per Cycle20 Amps
Minimum Load Current per Point10 mA
s

About IC693MDL350

The GE Fanuc IC693MDL350 module is a 16-point isolated output module manufactured as part of Series 90-30 of the GE PLCs (Programmable Logic Controllers.) It operates on a voltage rating of 120 to 240 Volts AC and it provides 16 separate isolated points. This module is designed for use with an AC power source when running the output loads. The IC693MDL350 module has an output current rating of 2 Amps per point, with a power consumption of approximately 315 milliamps at 5 Volts bus voltage. It comes with a DIP switch placed at the back that helps in determining how the CPU operates when it is stopped. This switch is specially designed for selecting the default mode. There are 2 DIP switches on the module, but only the upper one is used. This switch can turn off of the output whenever communication with the CPU is lost. The switch will alwats be in the righthand position when that happens. When the switch is in the lefthand position, the module output maintains the programmed value.







When the GE Fanuc Series 90-30 IC693MDL350 16-point isolated output module is in operation, the appropriate external fuses should be used to prevent short-circuiting. This module features LED indicators that show the presence of a detachable terminal block. The indicator glows green when the terminal block is connected and it glows red when the terminal block is removed. The IC693MDL350 module provides high-level noise immunity to protect the outputs against electrical noise, thus minimizing the need for using an external snubbe. The output of the GE Fanuc Series 90-30 IC693MDL350 module makes an impact on several inductive or incandescent loads.



Repair Services for IC693MDL350

Type Lead Time Price Action
Repair Service 2-4 weeks $636cartAdd to Cart

Our highly skilled technicians can repair your IC693MDL350. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for IC693MDL350

Please refer to the manual for more information about the IC693MDL350 such as the wiring diagrams, data sheets and migration or obsolescence details.
