IC693PWR332

Rated 4.8 with 12 reviews

Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for GE Fanuc.

top legal disclaimer
top legal disclaimer

credit cards accepted
better business bureau

IC693PWR332

Revisions: D K C D K
Description: The IC693PWR332 power supply module is manufactured by GE Fanuc and it is part of Series 90-30. It has a nominal voltage of 12 Volts DC and an input voltage range of 9.6 to 15 Volts DC. This high-capacity power supply module has a load capacity of 30 Watts and a maximum input power of 50 Watts at a full load.
In Stock Ships Today
Request a quote for IC693PWR332

Description:

The IC693PWR332 power supply module is manufactured by GE Fanuc and it is part of Series 90-30. It has a nominal voltage of 12 Volts DC and an input voltage range of 9.6 to 15 Volts DC. This high-capacity power supply module has a load capacity of 30 Watts and a maximum input power of 50 Watts at a full load.


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for GE Fanuc.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: D K C D K

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via UPS, DHL, and TNT
Repairs: We offer repair service for the IC693PWR332.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.8 with 12 reviews

    Technical Specifications for IC693PWR332

BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693PWR332
Nominal rated voltage12 Volts DC, nominal
Input voltage range9.6 to 15 Volts DC
Load capacity30 Watts
Input power50 Watts maximum at full load
Output capacities+5 Volts DC/30 Watts, +24 Volts DC isolated/20 Watts, +24 Volts DC relay/15 Watts
Inrush current4 Amps peak with maximum of 100 milliseconds
Ride-through time10 milliseconds (minimum)
Protective limits (overvoltage)5 Volts DC output with 6.4 to 7 Volts range
Protective limits (overcurrent)5 Volts DC output with 7 Volts maximum
Serial portRS-485
Product Lifecycle Status*Discontinued/Obsolete

*The GE Fanuc IC693PWR332 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement IC693PWR332 units instead of migration.

BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693PWR332
Nominal rated voltage12 Volts DC, nominal
Input voltage range9.6 to 15 Volts DC
Load capacity30 Watts
Input power50 Watts maximum at full load
Output capacities+5 Volts DC/30 Watts, +24 Volts DC isolated/20 Watts, +24 Volts DC relay/15 Watts
Inrush current4 Amps peak with maximum of 100 milliseconds
Ride-through time10 milliseconds (minimum)
Protective limits (overvoltage)5 Volts DC output with 6.4 to 7 Volts range
Protective limits (overcurrent)5 Volts DC output with 7 Volts maximum
Serial portRS-485
Product Lifecycle Status*Discontinued/Obsolete

*The GE Fanuc IC693PWR332 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement IC693PWR332 units instead of migration.

s

About IC693PWR332

The GE IC693PWR332 power supply module is intended for use in the high-performance industrial systems that are found in many different industries. The unit is part of Series 90-30 from the GE Fanuc company. This product series offers variety of PLCs and accessories like input/output devices, controllers, modules for specific applications, power supply modules like the IC693PWR332 module, and other components that provide extraordinary flexibility and reliability. These products are made for demanding industrial environments and they are made of high-quality materials that meet several industrial standards. The IC693PWR332 power supply module has an input voltage of 9.6 to 15 Volts DC and a nominal rated voltage of 12 Volts DC. The load capacity of the unit is 30 Watts and the input power is 50 Watts maximum when at a full load.







The IC693PWR332 power supply module is a high-capacity component that includes the following output capacities: 30 Watts at 5 Volts DC, 20 Watts at 24 Volts DC isolated voltage, and 15 Watts at 24 Volts DC relay. The unit has 4 system status indicators and it can be connected to lithium back-up battery in order to prevent system malfunctioning and delays. Besides that, the IC693PWR332 power supply module has a peak inrush current of 4 Amps for the duration of a maximum of 100 milliseconds. The ride-through time of the unit is a minimum of 10 milliseconds. The IC693PWR332 unit has a RS-486 compatible serial port and it provides protective limits of 5 Volts DC output with a 6.4 to 7 Volts range for over-voltage situations and of 5 Volts DC output with 7 Volts maximum for over-current situations. This module operates with an ambient temperature of up to 50 degrees Celsius (122 degrees Fahrenheit).



Repair Services for IC693PWR332

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC693PWR332. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for IC693PWR332

Please refer to the manual for more information about the IC693PWR332 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
IC693PWR332 D
IC693PWR332-D, Series D, Rev D Request Quote
IC693PWR332 K
IC693PWR332-K, Series K, Rev K Request Quote
IC693PWR332C
IC693PWR332-C, Series C, Rev C Request Quote
IC693PWR332D
IC693PWR332-D, Series D, Rev D Request Quote
IC693PWR332K
IC693PWR332-K, Series K, Rev K Request Quote
Common misspellings:
  • 1C693PWR332
  • IC693PWR332

Dimensions For IC693PWR332

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For IC693PWR332

Resolutions For IC693PWR332

About

Technical Specifications for IC693PWR332

BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693PWR332
Nominal rated voltage12 Volts DC, nominal
Input voltage range9.6 to 15 Volts DC
Load capacity30 Watts
Input power50 Watts maximum at full load
Output capacities+5 Volts DC/30 Watts, +24 Volts DC isolated/20 Watts, +24 Volts DC relay/15 Watts
Inrush current4 Amps peak with maximum of 100 milliseconds
Ride-through time10 milliseconds (minimum)
Protective limits (overvoltage)5 Volts DC output with 6.4 to 7 Volts range
Protective limits (overcurrent)5 Volts DC output with 7 Volts maximum
Serial portRS-485
Product Lifecycle Status*Discontinued/Obsolete
BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693PWR332
Nominal rated voltage12 Volts DC, nominal
Input voltage range9.6 to 15 Volts DC
Load capacity30 Watts
Input power50 Watts maximum at full load
Output capacities+5 Volts DC/30 Watts, +24 Volts DC isolated/20 Watts, +24 Volts DC relay/15 Watts
Inrush current4 Amps peak with maximum of 100 milliseconds
Ride-through time10 milliseconds (minimum)
Protective limits (overvoltage)5 Volts DC output with 6.4 to 7 Volts range
Protective limits (overcurrent)5 Volts DC output with 7 Volts maximum
Serial portRS-485
Product Lifecycle Status*Discontinued/Obsolete

*The GE Fanuc IC693PWR332 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement IC693PWR332 units instead of migration.

About IC693PWR332

The GE IC693PWR332 power supply module is intended for use in the high-performance industrial systems that are found in many different industries. The unit is part of Series 90-30 from the GE Fanuc company. This product series offers variety of PLCs and accessories like input/output devices, controllers, modules for specific applications, power supply modules like the IC693PWR332 module, and other components that provide extraordinary flexibility and reliability. These products are made for demanding industrial environments and they are made of high-quality materials that meet several industrial standards. The IC693PWR332 power supply module has an input voltage of 9.6 to 15 Volts DC and a nominal rated voltage of 12 Volts DC. The load capacity of the unit is 30 Watts and the input power is 50 Watts maximum when at a full load.







The IC693PWR332 power supply module is a high-capacity component that includes the following output capacities: 30 Watts at 5 Volts DC, 20 Watts at 24 Volts DC isolated voltage, and 15 Watts at 24 Volts DC relay. The unit has 4 system status indicators and it can be connected to lithium back-up battery in order to prevent system malfunctioning and delays. Besides that, the IC693PWR332 power supply module has a peak inrush current of 4 Amps for the duration of a maximum of 100 milliseconds. The ride-through time of the unit is a minimum of 10 milliseconds. The IC693PWR332 unit has a RS-486 compatible serial port and it provides protective limits of 5 Volts DC output with a 6.4 to 7 Volts range for over-voltage situations and of 5 Volts DC output with 7 Volts maximum for over-current situations. This module operates with an ambient temperature of up to 50 degrees Celsius (122 degrees Fahrenheit).



Repairs
Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC693PWR332. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC693PWR332. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions

Please refer to the manual for more information about the IC693PWR332 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
IC693PWR332 D
IC693PWR332/D, Series D, Rev D Request Quote
IC693PWR332 K
IC693PWR332/K, Series K, Rev K Request Quote
IC693PWR332C
IC693PWR332/C, Series C, Rev C Request Quote
IC693PWR332D
IC693PWR332/D, Series D, Rev D Request Quote
IC693PWR332K
IC693PWR332/K, Series K, Rev K Request Quote

Common misspellings:
  • IC693PWR332
