IC693TCM302

Revisions: A B
Description: The IC693TCM302 temperature control module that is manufactured by GE Fanuc is part of Series 90-30. The IC693TCM302 module is a thermocouple input module and it has an output voltage range of 18 to 30 Volts DC. The unit has a load current of 100 milliAmps and a maximum off-state leakage of 0.1 milliAmps. The module uses an internal power of 150 milliAmps at 5 Volts DC and it has 8 channels for both input and output.
In Stock Ships Today
Request a quote for IC693TCM302

Description:

The IC693TCM302 temperature control module that is manufactured by GE Fanuc is part of Series 90-30. The IC693TCM302 module is a thermocouple input module and it has an output voltage range of 18 to 30 Volts DC. The unit has a load current of 100 milliAmps and a maximum off-state leakage of 0.1 milliAmps. The module uses an internal power of 150 milliAmps at 5 Volts DC and it has 8 channels for both input and output.



top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: A B

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the IC693TCM302.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:


Rated 4.5 with 7 reviews

    Technical Specifications for IC693TCM302

BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693TCM302
Output voltage range18 to 30 Volts DC
External power supply18 to 36 Volts DC (2.5 Amps inrush)
Off-state leakage (maximum)0.1 milliAmps
Load current100 milliAmps
Internal power used150 milliAmps at 5 Volts DC
Number of channels8 input / 8 output
Overload threshold current700 milliAmps typical, 2 milliseconds minimum
Thermocouple impedance30 Ohms (maximum)
Operating temperature0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit)
Storage temperature-40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
Product Lifecycle Status*Discontinued/Obsolete

*The GE Fanuc - GE IP - Emerson IC693TCM302 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement IC693TCM302 units instead of migration.

BrandGE Fanuc
SeriesSeries 90-30
Part NumberIC693TCM302
Output voltage range18 to 30 Volts DC
External power supply18 to 36 Volts DC (2.5 Amps inrush)
Off-state leakage (maximum)0.1 milliAmps
Load current100 milliAmps
Internal power used150 milliAmps at 5 Volts DC
Number of channels8 input / 8 output
Overload threshold current700 milliAmps typical, 2 milliseconds minimum
Thermocouple impedance30 Ohms (maximum)
Operating temperature0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit)
Storage temperature-40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
Product Lifecycle Status*Discontinued/Obsolete

*The GE Fanuc - GE IP - Emerson IC693TCM302 has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement IC693TCM302 units instead of migration.

s

About IC693TCM302

The IC693TCM302 module is a temperature control module that is used for GE Fanuc programmable logic controllers or PLCs from Series 90-30. This high-performance and reliable industrial temperature control module is designed and manufactured by GE Fanuc and it allows the users to benefit from use of 8 input and output channels. The main purpose of this module is to make it easier for the users to control and monitor the temperature of their machines and systems. The input channels of the IC693TCM302 module are thermocouple input channels and its output channels are used for control purposes. The IC693TCM302 module has an output voltage range of 18 to 30 Volts DC and a load current of 100 milliAmps. In addition to that, the unit has a voltage rating of 18 to 36 Volts DC when it is used with an external power supply. The unit has an internal power rating of 150 milliAmps at a voltage of 5 Volts DC and it has a maximum off-state leakage current of 0.1 milliAmps.







The GE Fanuc Series 90-30 IC693TCM302 temperature control module features a typical overload threshold current of 700 milliAmps at a minimum of 2 milliseconds and a maximum thermocouple impedance rating of 30 Ohms. This module has an operating temperature range of 0 to 55 degrees Celsius (32 to 131 degrees Fahrenheit) and a storage temperature range of -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit). The IC693TCM302 temperature control module allows the users to choose either the automatic operating mode or the manual operating mode, depending on the requirements of the application for which it is used. This component also has 12 LED indicators for thermocouple status updates and they provides information about faults such as reverse polarity faults and open-circuit faults.



Repair Services for IC693TCM302

Type Lead Time Price Action
Repair Service 2-4 weeks $4745.25cartAdd to Cart

Our highly skilled technicians can repair your IC693TCM302. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for IC693TCM302

Please refer to the manual for more information about the IC693TCM302 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
IC693TCM302A
IC693TCM302-A, Series A, Rev A Request Quote
IC693TCM302B
IC693TCM302-B, Series B, Rev B Request Quote
Common misspellings:
  • 1C693TCM302
  • IC693TCM3o2
  • IC693TCM302

Dimensions For IC693TCM302
