IC697CPU772

Description: The GE Fanuc IC697CPU772 module is a CPU module. The IC697CPU772 supports a maximum 512 kilobytes of user memory.
In Stock Ships Today
Request a quote for IC697CPU772

Description:

The GE Fanuc IC697CPU772 module is a CPU module. The IC697CPU772 supports a maximum 512 kilobytes of user memory.


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for GE Fanuc.

top legal disclaimer
disclaimer

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the IC697CPU772.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 5 with 6 reviews

    Technical Specifications for IC697CPU772

BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697CPU772
Product typeCPU module
CompatibilityGE Fanuc 90-70 PLCs
Voltage input5 Volts DC
Current draw1.2 Amps
Maximum battery512 kilobytes
Clock speed12 Megahertz
Microprocessor80C186
Serial port1
BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697CPU772
Product typeCPU module
CompatibilityGE Fanuc 90-70 PLCs
Voltage input5 Volts DC
Current draw1.2 Amps
Maximum battery512 kilobytes
Clock speed12 Megahertz
Microprocessor80C186
Serial port1
s

About IC697CPU772

The IC697CPU772 module is a CPU module which is compatible with Series 90-70 programmable logic controllers from GE Fanuc. The Series 90-70 product line is a family of PLCs and PLC components which provide a full-function controller that is easy to configure and install in any system. The Series 90-70 PLCs are designed to be compatible with other PLCs which form part of the larger GE Fanuc Series 90 PLC family. The Series 90-70 line includes a large number of different PLC system components including CPU modules, racks. I/O systems, power supplies, Genius I/O, and numerous optional modules. The architecture of the CPU modules is based on the Intel 80X86 or 80X86DX processor. The IC697CPU772 module uses an 80C186 microprocessor with a 12 Megahertz system clock.







The IC697CPU772 module takes up one slot in the PLC rack. Floating point operations are supported on the CPU module. The system memory is expandable because 64, 128, 256, and 512 KB CMOS expansion memory modules can be installed on the IC697CPU772 module. A replaceable system battery provides backup power to the program and data memory in case the system power is removed. The old battery must be removed before the replacement battery is installed. The current required by the IC697CPU772 module from the 5 Volts DC bus is 1.2 Amps. This current requirement includes the current consumed by the expansion memory. The IC697CPU772 module is configured through either MS-DOS or Microsoft Windows based programming tools. To ensure there are no deviations from the programmed configuration, the CPU verifies the actual configuration at boot-up and periodically during system operation. The integrated serial port can be used to interface with a serial programmer.



Repair Services for IC697CPU772

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC697CPU772. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for IC697CPU772

Please refer to the manual for more information about the IC697CPU772 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
ic697cpu772F
IC697CPU772-ic697cpu772F, Series ic697cpu772F, Rev ic697cpu772F Request Quote
ic697cpu772J
IC697CPU772-ic697cpu772J, Series ic697cpu772J, Rev ic697cpu772J Request Quote
ic697cpu772K
IC697CPU772-ic697cpu772K, Series ic697cpu772K, Rev ic697cpu772K Request Quote
ic697cpu772L
IC697CPU772-ic697cpu772L, Series ic697cpu772L, Rev ic697cpu772L Request Quote
Common misspellings:
  • 1C697CPU772
  • IC697CPU772

Dimensions For IC697CPU772

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For IC697CPU772

Resolutions For IC697CPU772

About

Technical Specifications for IC697CPU772

BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697CPU772
Product typeCPU module
CompatibilityGE Fanuc 90-70 PLCs
Voltage input5 Volts DC
Current draw1.2 Amps
Maximum battery512 kilobytes
Clock speed12 Megahertz
Microprocessor80C186
Serial port1
BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697CPU772
Product typeCPU module
CompatibilityGE Fanuc 90-70 PLCs
Voltage input5 Volts DC
Current draw1.2 Amps
Maximum battery512 kilobytes
Clock speed12 Megahertz
Microprocessor80C186
Serial port1

About IC697CPU772

The IC697CPU772 module is a CPU module which is compatible with Series 90-70 programmable logic controllers from GE Fanuc. The Series 90-70 product line is a family of PLCs and PLC components which provide a full-function controller that is easy to configure and install in any system. The Series 90-70 PLCs are designed to be compatible with other PLCs which form part of the larger GE Fanuc Series 90 PLC family. The Series 90-70 line includes a large number of different PLC system components including CPU modules, racks. I/O systems, power supplies, Genius I/O, and numerous optional modules. The architecture of the CPU modules is based on the Intel 80X86 or 80X86DX processor. The IC697CPU772 module uses an 80C186 microprocessor with a 12 Megahertz system clock.







The IC697CPU772 module takes up one slot in the PLC rack. Floating point operations are supported on the CPU module. The system memory is expandable because 64, 128, 256, and 512 KB CMOS expansion memory modules can be installed on the IC697CPU772 module. A replaceable system battery provides backup power to the program and data memory in case the system power is removed. The old battery must be removed before the replacement battery is installed. The current required by the IC697CPU772 module from the 5 Volts DC bus is 1.2 Amps. This current requirement includes the current consumed by the expansion memory. The IC697CPU772 module is configured through either MS-DOS or Microsoft Windows based programming tools. To ensure there are no deviations from the programmed configuration, the CPU verifies the actual configuration at boot-up and periodically during system operation. The integrated serial port can be used to interface with a serial programmer.



Repairs
Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC697CPU772. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC697CPU772. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions

Please refer to the manual for more information about the IC697CPU772 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
ic697cpu772F
IC697CPU772/ic697cpu772F, Series ic697cpu772F, Rev ic697cpu772F Request Quote
ic697cpu772J
IC697CPU772/ic697cpu772J, Series ic697cpu772J, Rev ic697cpu772J Request Quote
ic697cpu772K
IC697CPU772/ic697cpu772K, Series ic697cpu772K, Rev ic697cpu772K Request Quote
ic697cpu772L
IC697CPU772/ic697cpu772L, Series ic697cpu772L, Rev ic697cpu772L Request Quote

Common misspellings:
  • IC697CPU772
