IC697MDL241

Revisions: C
Description: The GE Fanuc IC697MDL241 Discrete Input Module is manufactured as part of the Series 90-70 product line. This module has an operating voltage of 240 Volts AC and it comes with 16 isolated input points. It also has an input filter time of 20 milliseconds and it is compatible with the proximity switch.
In Stock Ships Today
Request a quote for IC697MDL241

Description:

The GE Fanuc IC697MDL241 Discrete Input Module is manufactured as part of the Series 90-70 product line. This module has an operating voltage of 240 Volts AC and it comes with 16 isolated input points. It also has an input filter time of 20 milliseconds and it is compatible with the proximity switch.


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for GE Fanuc.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: C

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the IC697MDL241.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 5 with 17 reviews

    Technical Specifications for IC697MDL241

BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697MDL241
BrandGE Intelligent Platforms/GE Fanuc
Product TypeDiscrete Input Module
Voltage240 V AC
Inputs16 point Isolated
Input Current 20 mA
Current Required0.25 A
Frequency60 Hz
DC powerNo
AC PowerYes
LED IndicatorsYes
BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697MDL241
BrandGE Intelligent Platforms/GE Fanuc
Product TypeDiscrete Input Module
Voltage240 V AC
Inputs16 point Isolated
Input Current 20 mA
Current Required0.25 A
Frequency60 Hz
DC powerNo
AC PowerYes
LED IndicatorsYes
s

About IC697MDL241

The IC697MDL241 Input Module is a discrete input module manufactured by GE Fanuc as part of Series 90-70. It operates on 240 Volts AC voltage rating and it features 16 separate isolated points with an input filter time of 20 milliseconds and proximity switch compatibility. This module is designed and intended for use with Programmable Logic Controllers (PLCs), and each isolated input can function as a single AC supply phase. It also has inputs that are reactive with the IEC standard current-voltage properties, which are compatible with different proximity switches. The GE Fanuc IC697MDL241 Module features LEDs for indicating the on and off status for each of the points on the circuit logic side. The LEDs are found on top of the module.







The GE Fanuc IC697MDL241 Discrete Input Module is mechanically keyed to provide easy replacement with a corresponding module type in the field. The users can configure the I/O references and DIP jumpers or switches are not required. These configurations can be completed through the configuration functionality of the Windows or MS-DOS programming software that runs on the Windows NT or Windows 95 operating system through the SNP port or Ethernet TCP/IP port. The programming software configuration function is preinstalled. The IC697MDL241 Module is matched with a collection of input devices such as limit switches, selector switches, pushbuttons, and 2-wire and 3-wire electronic proximity switches. The IC697MDL241 Module has capacitive input circuitry that ensures that there is low heat dissipation, and this contributes to the reliability and long life of the module. It has a typical input current of 10 milliamps in the on-state and it can also sink a leakage current of up to 5 milliamps in the off-state.



Repair Services for IC697MDL241

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC697MDL241. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for IC697MDL241

Please refer to the manual for more information about the IC697MDL241 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
IC697MDL241C
IC697MDL241-C, Series C, Rev C Request Quote
Common misspellings:
  • 1C697MDL241
  • IC697MD1241
  • IC697MDL2A1
  • IC697MDL24l
  • IC697MDL241

Dimensions For IC697MDL241

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm

Dimensions For IC697MDL241

Resolutions For IC697MDL241

About

Technical Specifications for IC697MDL241

BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697MDL241
BrandGE Intelligent Platforms/GE Fanuc
Product TypeDiscrete Input Module
Voltage240 V AC
Inputs16 point Isolated
Input Current 20 mA
Current Required0.25 A
Frequency60 Hz
DC powerNo
AC PowerYes
LED IndicatorsYes
BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697MDL241
BrandGE Intelligent Platforms/GE Fanuc
Product TypeDiscrete Input Module
Voltage240 V AC
Inputs16 point Isolated
Input Current 20 mA
Current Required0.25 A
Frequency60 Hz
DC powerNo
AC PowerYes
LED IndicatorsYes

About IC697MDL241

The IC697MDL241 Input Module is a discrete input module manufactured by GE Fanuc as part of Series 90-70. It operates on 240 Volts AC voltage rating and it features 16 separate isolated points with an input filter time of 20 milliseconds and proximity switch compatibility. This module is designed and intended for use with Programmable Logic Controllers (PLCs), and each isolated input can function as a single AC supply phase. It also has inputs that are reactive with the IEC standard current-voltage properties, which are compatible with different proximity switches. The GE Fanuc IC697MDL241 Module features LEDs for indicating the on and off status for each of the points on the circuit logic side. The LEDs are found on top of the module.







The GE Fanuc IC697MDL241 Discrete Input Module is mechanically keyed to provide easy replacement with a corresponding module type in the field. The users can configure the I/O references and DIP jumpers or switches are not required. These configurations can be completed through the configuration functionality of the Windows or MS-DOS programming software that runs on the Windows NT or Windows 95 operating system through the SNP port or Ethernet TCP/IP port. The programming software configuration function is preinstalled. The IC697MDL241 Module is matched with a collection of input devices such as limit switches, selector switches, pushbuttons, and 2-wire and 3-wire electronic proximity switches. The IC697MDL241 Module has capacitive input circuitry that ensures that there is low heat dissipation, and this contributes to the reliability and long life of the module. It has a typical input current of 10 milliamps in the on-state and it can also sink a leakage current of up to 5 milliamps in the off-state.



Repairs
Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC697MDL241. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC697MDL241. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions

Please refer to the manual for more information about the IC697MDL241 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
IC697MDL241C
IC697MDL241/C, Series C, Rev C Request Quote
