IC697MDL252

Description: The GE Fanuc IC697MDL252 discrete input module is manufactured as a part of GE Series 90-70. This module features 4 isolated groups with 8 points each for a total of 32 points. It also has an input filter of 20 milliseconds and is compatible with the proximity switches.
Available Now
Request a quote for IC697MDL252

Description:

The GE Fanuc IC697MDL252 discrete input module is manufactured as a part of GE Series 90-70. This module features 4 isolated groups with 8 points each for a total of 32 points. It also has an input filter of 20 milliseconds and is compatible with the proximity switches.



Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the IC697MDL252.
Exchange: Exchange credit for your defective unit available.

To speak to a sales representative for pricing & lead time:


Rated 4.7 with 11 reviews

    Technical Specifications for IC697MDL252

BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697MDL252
BrandGE Intelligent Platforms/GE Fanuc
Product TypeDiscrete Input Module
Rated Voltage12 V AC
Inputs32
Input Current10 mA
Required Current0.30 A
Frequency47-63 Hz
DC PowerNo
AC PowerYes
LED IndicatorsYes
BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697MDL252
BrandGE Intelligent Platforms/GE Fanuc
Product TypeDiscrete Input Module
Rated Voltage12 V AC
Inputs32
Input Current10 mA
Required Current0.30 A
Frequency47-63 Hz
DC PowerNo
AC PowerYes
LED IndicatorsYes
s

About IC697MDL252

The IC697MDL252 discrete input module is a product of GE Fanuc. This module belongs to GE Series 90-70. Some of the notable features of this module include 4 individual groups of 8 input points for a total of 32 points. It has 20 milliseconds of input filter time and it is also compatible with the proximity switches. It runs on 12 Volts AC voltage and it works with various input devices, such as the limit switch, pushbuttons, selector switches, and the electronic 2-wire or 3-wire proximity switches. Since the IC697MDL252 input module features isolated input points, with each one on a distinct AC supply phase, it has a resistive input which adheres to the IEC standard type 1 requirements and has current-voltage characteristics. This module features LED indicators showing the on and off status for each of the input points on logic/PLC circuit side. The indicators are found on the top of the module.







The GE Fanuc IC697MDL252 Series 90-70 input module is tuned automatically, thus ensuring that its eventual replacement with a corresponding module type is done appropriately. The operators of this module can configure the input and output references without using DIP switches or jumpers. This configuration is done through the Windows programming software or the MS-DOS software which operates on Windows NT or Windows 95 via the Ethernet TCP/IP or the SNP port. The configuration function software is already installed on the device. The GE Fanuc IC697MDL252 input module has an input circuitry that offers sufficient current for guaranteeing the reliable and steady operation of the switching device. It comes with 10 milliamps of input current in the on-state and also accepts 2 milliamps of leakage current at maximum in the off-state without being switched on.



Repair Services for IC697MDL252

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC697MDL252. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for IC697MDL252

Please refer to the manual for more information about the IC697MDL252 such as the wiring diagrams, data sheets, firmware information and migration or obsolescence details.

Revision Part # Also Known as Availability
Common misspellings:
  • 1C697MDL252
  • IC697MD1252
  • IC697MDL252

Dimensions For IC697MDL252

Size
Input Type
Panel Cutout Height in mm
Panel Cutout Width in mm
Terminal Height in mm
Terminal Width in mm
Terminal Overall Depth in mm
Terminal Mounted Depth in mm
