IC697MDL652

Revisions: D
Description: The positive/negative logic input module that is known as the IC697MDL652 module is designed and manufactured by GE Fanuc and it is part of GE Series 90-70. The module has 32 input points and a rated voltage of 12 Volts DC. The module has an input current of 4.7 milliAmps and an input voltage range of -2.5 to 15 Volts DC.
In Stock Ships Today
Request a quote for IC697MDL652

Description:

The positive/negative logic input module that is known as the IC697MDL652 module is designed and manufactured by GE Fanuc and it is part of GE Series 90-70. The module has 32 input points and a rated voltage of 12 Volts DC. The module has an input current of 4.7 milliAmps and an input voltage range of -2.5 to 15 Volts DC.


Preowned

Includes a 1-Year DO Supply warranty.

DO Supply is not an authorized distributor for GE Fanuc.

top legal disclaimer
disclaimer
credit cards
better business bureau
Revisions: D

Warranty: 1 year DO Supply Warranty Included
Shipping: Worldwide shipping via DHL, UPS, Fedex, and TNT
Repairs: We offer repair service for the IC697MDL652.
Exchange: Exchange credit for your defective unit available.
Conditions: We sell preowned surplus and refurbished parts.

To speak to a sales representative for pricing & lead time:


Rated 4.5 with 8 reviews

    Technical Specifications for IC697MDL652

BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697MDL652
Rated voltage12 Volts DC
Input current4.7 milliAmps
Input voltage range-2.5 to 15 Volts DC
Required current0.3 Amps
Number of inputs32
Isolation voltage1500 Volts
ON-state voltage7.5 to 15 Volts
OFF-state voltage0 to 2.5 Volts
ON-state current6 to 15 milliAmps
OFF-state current0 to 2.5 milliAmps
BrandGE Fanuc
SeriesSeries 90-70
Part NumberIC697MDL652
Rated voltage12 Volts DC
Input current4.7 milliAmps
Input voltage range-2.5 to 15 Volts DC
Required current0.3 Amps
Number of inputs32
Isolation voltage1500 Volts
ON-state voltage7.5 to 15 Volts
OFF-state voltage0 to 2.5 Volts
ON-state current6 to 15 milliAmps
OFF-state current0 to 2.5 milliAmps
s

About IC697MDL652

The IC697MDL652 module is a type of positive/negative logic input module that is made by GE Fanuc. This module is available through Series 90-70 and it requires a current rating of 0.3 Amps. The rated voltage of the module is 12 Volts DC and its input current is 4.7 milliAmps. The IC697MDL652 module comes with faceplate LED indicators for status updates and it features a selectable input filter option. The users can choose either 1 millisecond or 10 milliseconds-rated input filters. Other features include use with proximity switches, positive/negative logic compatibility, interrupt single input, different configuration options, high performance with industrial components such as programmable logic controllers, limit and selector switches, and pushbuttons.







The IC697MDL652 module offers 32 input points arranged in 4 groups of 8. All input points are completely controlled by the module and the module is perfectly compatible with many PLC devices from the series. The IC697MDL652 module has an input voltage range of -2.5 to 15 Volts DC and it is designed for systems connected to DC power sources. The module has an isolation voltage of 1500 Volts for backplane inputs and 500 Volts for input groups. The typical impedance for the input of the module is 1.12 kiloohms. In regard to the other input characteristics, the IC697MDL652 module has an on-state voltage of 7.5 to 15 Volts and an off-state voltage of 0 to 2.5 Volts. In addition to that, the on-state current of the unit is 6 to 16 milliAmps while its off-state current is 0 to 2.5 milliAmps. The module is made according to VME (standard C.1) and it is a highly reliable component that operates as part of complex industrial systems.



Repair Services for IC697MDL652

Type Lead Time Price Action
Repair Service 2-4 weeks Askenvelope Get Quote

Our highly skilled technicians can repair your IC697MDL652. All of our repairs come with a 1 Year DO Supply Warranty. Please contact us for additional information about our repair process.

Revisions for IC697MDL652

Please refer to the manual for more information about the IC697MDL652 such as the wiring diagrams, data sheets and migration or obsolescence details.

Revision Part # Also Known as Availability
IC697MDL652D
IC697MDL652-D, Series D, Rev D Request Quote
