GE Fanuc Emerson Series Six IC600BF900

Product image is representative; revision or series may vary. Contact us to request a specific version.

IC600BF900

|
Need a Specific Revision?

The IC600BF900 from GE Fanuc Emerson is an I/O interface transmitter module designed to effectively link the local I/O rack with downstream equipment. This unit operates within a temperature range suitable for a variety of environments, ensuring reliable performance up to 60 °C.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for IC600BF900

ManufacturerGE Fanuc Emerson
Product TypeI/O Interface Transmitter Module
Product LineSeries Six
Part NumberIC600BF900
Weight6.00 lbs (2.72 kg)
FunctionInterfaces the local I/O rack to downstream racks
Normal Mode Capacity1 I/O chain per CPU
Expanded Mode Capacity8 I/O chains
Indicators TypeLED
Min. Operating Temperature0 °C
Max. Operating Temperature60 °C
Min. Storage Temperature-40 °C
Max. Storage Temperature85 °C
Installation Altitude1000 m
Min. Relative Humidity5% (Non-Condensing)
Max. Relative Humidity95% (Non-Condensing)
Request a Repair

The IC600BF900 I/O interface transmitter module by GE Fanuc Emerson features critical roles in connecting local I/O racks to associated downstream racks. Designed for flexibility, this module permits normal operation with a single I/O chain per CPU. For more extensive configurations, it can handle up to 8 I/O chains in expanded mode. LED indicators provide clear status feedback, essential for monitoring functionality.

In terms of environmental specifications, the module functions effectively within temperatures from 0 °C to 60 °C, ensuring reliable operation in various settings. When not in use, it can be stored in temperatures ranging from -40 °C to 85 °C, accommodating diverse environmental conditions. The device operates efficiently at an installation altitude of up to 1000 meters and supports relative humidity levels from 5% to 95% without condensation, which allows versatility in installation environments.
