Product image is representative; revision or series may vary. Contact us to request a specific version.
THN3362R
The THN3362R safety switch from GE Fanuc Emerson is designed for reliable performance in various industrial applications. It operates at a voltage rating of 600 VAC and supports three poles, ensuring effective circuit safety.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for THN3362R
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Safety Switch |
| Product Line | Spec-Setter Safety Switches |
| Part Number | THN3362R |
| UPC | 783164011319 |
| Rated Voltage | 600 VAC |
| Rated Current | 60 A |
| Number of Poles | 3 Poles |
| Number of Wires | 3 Wires |
| Enclosure Type | NEMA 3R |
| Wire Range | 12-2 AWG |
| 240 VAC, NEC Std, 1-ph | 10.0 Hp |
| 240 VAC, NEC Std, 3-ph | 20 Hp |
| 480 VAC, NEC Std, 1-ph | 20 Hp |
| 480 VAC, NEC Std, 3-ph | 50 Hp |
| 600 VAC, NEC Std, 1-ph | 25.0 Hp |
| 600 VAC, NEC Std, 3-ph | 60.0 Hp |
The THN3362R model from GE Fanuc Emerson is a robust safety switch incorporated in the Spec-Setter Safety Switches series. This unit has a significant rated voltage of up to 600 VAC and can handle a maximum current of 60 Amps clearly. The switch is structured with three poles and three wires, making it apt for various configurations.
An enclosure type classified as NEMA 3R offers resilient protection against environmental factors such as rain and falling debris, enhancing its usability in outdoor settings. The wire range specification allows for compatibility with wire sizes from 12 AWG to 2 AWG, accommodating different connection requirements.
It meets National Electrical Code (NEC) standards allowing it to efficiently handle various horsepower capacities. Under 240 VAC, the rated horsepower is 10.0 for single-phase and 20.0 for three-phase. Similar capabilities emerge at 480 VAC, with 20 Hp for single-phase and 50 Hp for three-phase applications. Finally, at 600 VAC, the switch can manage 25 Hp for single-phase and up to 60 Hp for three-phase operations. This safety switch is well-engineered for secure and effective operation across a variety of electrical systems.
