Product image is representative; revision or series may vary. Contact us to request a specific version.
THN3363R
The THN3363R is a heavy-duty safety switch produced by GE Fanuc Emerson in the Spec-Setter series. This switch is rated for 100 amperes and can handle a maximum voltage of 600 volts AC, making it suitable for various applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for THN3363R
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Heavy Duty Safety Switch |
| Product Line | Spec-Setter Safety Switches |
| Part Number | THN3363R |
| UPC | 783164011333 |
| Amperage Rating | 100 Amperes |
| Voltage Rating | 600 Volts AC (max) |
| Poles | 3 Poles |
| Enclosure | NEMA 3R |
| Fusibility | Non Fusible |
| Protection | Manual Disconnect Only |
| Mounting | Surface Mount |
| Power | 60 HP (standard), 75 HP (max) |
| Certification | UL, CSA |
| Wire Size Range | 10-1/0 AWG |
The THN3363R safety switch from GE Fanuc Emerson is built for demanding environments. As a heavy-duty unit, it possesses an amperage rating of 100 A and supports a maximum voltage of 600 VAC. This device features three poles, providing reliable circuit guarding. The switch utilizes a NEMA 3R enclosure, promoting weather resistance for applications that may be exposed to the elements.
Designed with manual disconnect protection, the THN3363R prioritizes safety in operation. It is a non-fusible switch, ensuring maintenance simplicity while adhering to UL and CSA certifications. The mounting type for this switch is surface, facilitating straightforward installation in various settings.
In typical operational scenarios, the unit can manage power loads of 60 horsepower under standard conditions, and it can reach up to 75 horsepower at maximum capacity. Additionally, it accommodates wire sizes ranging from 10 AWG to 1/0 AWG, making it versatile for different electrical configurations. Overall, the THN3363R is engineered to meet the requirements of heavy-duty applications, ensuring secure power management.
