Product image is representative; revision or series may vary. Contact us to request a specific version.
THN3366R
The GE Fanuc Emerson THN3366R is a robust non-fused safety switch designed for heavy-duty applications. It is rated for 600 VAC and up to 600 A, suitable for outdoor environments with an NEMA 3R enclosure.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for THN3366R
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Heavy Duty Non-Fused Safety Switch |
| Product Line | Spec-Setter Safety Switches |
| Part Number | THN3366R |
| UPC | 783164011395 |
| AC Voltage Rating | 600 VAC |
| Amperage Rating | 600 A |
| Enclosure Type | NEMA 3R (Outdoor) |
| Fuse | Not Included |
| Number of Wires | 3 Wires |
| Number of Poles | 3 Poles |
| Unit Type | Heavy Duty |
| Horsepower Rating at 250 VDC | 50 Horsepower |
| DC Voltage Rating | 250 VDC |
| Horsepower Rating at 600 VAC (NEC Standard 3 Phase) | 500 Horsepower |
The THN3366R model from GE Fanuc Emerson is engineered as a heavy-duty, non-fused safety switch. It handles an AC voltage of 600 VAC and is capable of managing a maximum current rating of 600 A. This unit is specifically built for outdoor installation, conforming to the NEMA 3R standards for environmental protection. Designed to function without fuses, the switch can efficiently manage three incoming wires across three poles.
For DC applications, the THN3366R supports a voltage rating of up to 250 VDC and maintains a horsepower capability of 50 at this rating. In 3-phase systems at 600 VAC, it can handle loads up to 500 horsepower, complying with NEC standards. This operational capacity ensures that the switch can be utilized effectively in a wide range of demanding industrial situations.
