SEPA36AT0060
The SEPA36AT0060 from GE Fanuc Emerson is a circuit breaker that operates effectively with a maximum rated current of 60 A. It is designed with solid state protection for reliable performance across various voltage levels.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for SEPA36AT0060
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Circuit Breaker |
| Product Line | Spectra |
| Part Number | SEPA36AT0060 |
| UPC | 78316421149 |
| Number of Poles | 3 Poles |
| Maximum Rated Current | 60 A |
| Protection Type | Solid State Protection |
| Interrupting Rating at 120 VAC To 240 VAC | 200 kAIC |
| Rated Voltage Options | 120 VAC, 120/240 VAC, 240 VAC, 277 VAC, 480 VAC, 600 VAC |
| Phase Type | 3-Phase |
| Connection Type | Bolt-on Connection |
| Interrupting Rating at 277 VAC to 480 VAC | 100 kAIC |
| Interrupting Rating at 600 VAC | 25 kAIC |
| Installation Altitude | 1000 MSL |
The GE Fanuc Emerson SEPA36AT0060 is recognized for its solid state protection, ensuring consistent operation under varying conditions. It is a three-pole circuit breaker with a maximum current capacity of 60 A. Designed for flexibility, it supports several voltage ratings: 120 VAC, 120/240 VAC, 240 VAC, 277 VAC, 480 VAC, and 600 VAC.
This circuit breaker offers superior protection with an interrupting capacity of 200 kAIC in the voltage range of 120 VAC to 240 VAC, enabling it to effectively manage fault currents. For higher voltage applications, it maintains a rating of 100 kAIC from 277 VAC to 480 VAC and 25 kAIC at 600 VAC.
With a bolt-on connection type, installation is straightforward. It operates effectively in three-phase systems and can be installed in environments up to 1000 meters above mean sea level, making it suitable for various applications across different industries.
