GE Fanuc Emerson Spectra SGHA36AT0400

Product image is representative; revision or series may vary. Contact us to request a specific version.

SGHA36AT0400

|
Need a Specific Revision?

The SGHA36AT0400 circuit breaker from GE Fanuc Emerson's Spectra series offers robust protection with a 400 Amp rating and solid state electronic trip unit for reliable performance.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for SGHA36AT0400

ManufacturerGE Fanuc Emerson
Product TypeCircuit Breaker
Product LineSpectra
Part NumberSGHA36AT0400
UPC783164211641
Frame TypeSG600 (G-Frame)
Trip Unit TypeSolid State Electronic (Spectra RMS)
Trip FunctionsLSI (Long-Time, Short-Time, Instantaneous)
Trip AdjustabilityInterchangeable Rating Plugs
Amperage Rating400 Amps
Number of Poles3 Poles
Maximum Voltage600 volts
Interrupting Rating35 kA (kAIC) at 480 volts, 65 kA (kAIC) at 240 volts, 25 kA (kAIC) at 600 volts
Connection TypeBolt-On
CertificationsUL Listed, CSA Certified
Request a Repair

The SGHA36AT0400, part of the Spectra series by GE Fanuc Emerson, functions as a solid circuit protection component. It can handle an amperage rating of 400 Amps and is structured with a G-Frame (SG600) type, indicating its robustness. The circuit breaker operates at a maximum of 600 volts across its 3 poles.

Featuring a solid state electronic trip unit (Spectra RMS), this product provides advanced trip functionalities like long-time, short-time, and instantaneous responses tailored to changing electrical conditions. Users can easily adjust the trip settings through interchangeable rating plugs, enhancing adaptability based on operational needs.

This breaker can withstand various fault conditions with impressive interrupting ratings: 35 kA at 480 volts, 65 kA at 240 volts, and 25 kA at 600 volts. Connection is achieved via a bolt-on method which offers secure installation and reliability. Furthermore, the SGHA36AT0400 boasts certifications from UL and CSA, affirming its compliance with industry safety standards.
