SRPF250A150
The SRPF250A150 rating plug from GE Fanuc Emerson is intended for use in the Spectra series. With a substantial frame rating of 250 A and a plug current rating of 150 A, this model is capable of supporting 3-pole circuits, making it versatile for various applications.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for SRPF250A150
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Rating Plug |
| Product Line | Spectra |
| Part Number | SRPF250A150 |
| UPC | 783164213218 |
| Frame Rating | 250 A |
| Plug Current Rating | 150 A |
| Poles Supported | 3-pole Compatible |
| Trip Type | Long-time Trip Adjustment |
| Interchangeability | UL-listed Interchangeable |
| Mounting Type | Plug-in Accessory for SF250 Frame |
| Voltage Class | 600 VAC Maximum |
| Interrupt Rating Compatibility | Matches Breaker Frame Rating (up to 65 kAIC depending on breaker) |
| Connection Type | Direct Insertion into Breaker Rating Socket |
| Calibration | Factory-calibrated RMS Sensing |
| Frequency Rating | 50/60 Hz |
| Insulation Class | Molded Case Insulation per UL 489 |
| Dielectric Withstand | 2200 V RMS for 1 Minute |
The GE Fanuc Emerson SRPF250A150 rating plug is a precise instrument designed to enhance circuit protection in electrical systems. Rated at 250 A, this product is constructed to accommodate a plug current of 150 A. It is compatible with three-pole configurations, allowing for widespread applicability in complex circuits.
The unit features a long-time trip adjustment, which ensures reliable performance during prolonged overload conditions. Notably, the SRPF250A150 is UL-listed, affirming its interchangeability with other approved devices, and it is designed as a plug-in accessory specifically for the SF250 frame. This facilitates hassle-free installation and maintenance.
Maximum operating voltage for this rating plug is 600 VAC, ensuring capability in demanding electrical environments. Its interrupt rating is adaptable, aligning with the breaker frame's rating and supporting up to 65 kAIC based on the type of breaker in use. A direct insertion connection allows for straightforward integration into the breaker’s rating socket.
Factory calibration utilizes RMS sensing for accurate measurements, guaranteeing precise operation. Designed for standard frequency ratings of 50 to 60 Hz, the insulation class complies with UL 489 standards for molded case insulation. Furthermore, the dielectric withstand test confirms resilience with a rating of 2200 V RMS for one minute, ensuring durability and reliability in critical applications.
