GE Fanuc Emerson Spectra TEB132015

Product image is representative; revision or series may vary. Contact us to request a specific version.

TEB132015

|
Need a Specific Revision?

The GE Fanuc Emerson TEB132015 is a thermal magnetic circuit breaker specialized for applications requiring reliable protection. This device is designed for 3-phase systems with a rated current of 15 Amps and a voltage rating of 240 VAC.

Call for an immediate quote
2 Year DO Supply Warranty
Available
Ships from Raleigh, NC
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for TEB132015

ManufacturerGE Fanuc Emerson
Product TypeThermal Magnetic Circuit Breaker
Product LineSpectra
Part NumberTEB132015
UPC783164068788
Number of Poles3 Poles
Rated Current15 A
Frame TypeE150 Frame
Phase Type3-Phase
Rated Voltage240 VAC
Interrupting Rating10 kAIC
FunctionsLong-Time and Instantaneous (LI)
Terminal ConnectionLug Connection
Operating Humidity80% (Non-Condensing)
Installation Altitude1000 MSL
Request a Repair

Belonging to the Spectra series, the TEB132015 from GE Fanuc Emerson is a thermal magnetic circuit breaker designed for optimal circuit protection in industrial settings. The breaker operates effectively in 3-phase configurations, supported by a robust rated current of 15 A and a voltage rating of 240 VAC.

This unit features three poles and is structured around an E150 frame type, providing solid performance. It incorporates long-time and instantaneous trip functions, labeled as LI, for sensitive operational control. With an interrupting rating of 10 kAIC, the TEB132015 ensures that it can effectively handle fault conditions.

The breaker connects through lug terminals, simplifying installation. Constructed to function reliably up to 1000 meters above sea level, it maintains full operational efficiency in appropriate conditions. The device is also rated for an operating humidity of 80%, ensuring it performs effectively in varied environmental conditions without condensation risks.
