TEYD2040B
The GE Fanuc Emerson TEYD2040B is a molded case circuit breaker designed for reliable protection in various electrical applications. Rated at 40 amperes, it operates effectively across a voltage range that includes both AC and DC. Its compact design involves a two-pole configuration suitable for 1-phase systems.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for TEYD2040B
| Manufacturer | GE Fanuc Emerson |
|---|---|
| Product Type | Molded Case Circuit Breaker |
| Product Line | Spectra |
| Part Number | TEYD2040B |
| UPC | 783164461619 |
| Operating Amperage | 40 Amperes |
| Working Frequency | 50 to 60 Hertz |
| Wire Range | 10 to 4 American Wire Gauge (AWG) |
| Phase Rating | 1-phase |
| Trip Functions | Long-Time and Instantaneous (LI) |
| System Voltage | 120/240 Volts, 277/480 Volts AC, and 250 Volts DC |
| Number of Poles | 2 poles |
| Connection Type | Bolt-on |
| Breaker Interrupt Rating | 25 kiloamperes at 277/480 Volts and 65 kiloamperes at 120/240 Volts AC |
| Terminal Connection | Load side lugs |
| Actuator Type | Handle |
| Type of Frame | TEYD frame |
The TEYD2040B molded case circuit breaker by GE Fanuc Emerson is engineered for robust electrical protection and application versatility. With an operating amperage of 40A, this breaker can handle substantial electrical loads. It is compatible with a voltage system that includes 120/240 Volts and 277/480 Volts AC, along with 250 Volts DC.
This unit is designed for 1-phase operations and incorporates a two-pole configuration for effective circuit management. The TEYD frame gives it structural strength, making it suitable for various installations. Users can wire it to accommodate conductors in the range of 10 to 4 AWG.
The breaker operates efficiently within a frequency range of 50 to 60 Hertz. It features trip functions that are classified as long-time and instantaneous (LI), providing comprehensive protection against both overloads and fault conditions. It is mounted with a bolt-on connection type, enhancing its stability in installations. Terminal connections are made via load side lugs, ensuring secure power delivery.
For safety, the TEYD2040B possesses an interrupt capacity that reaches 25 kiloamperes at 277/480 Volts and 65 kiloamperes at 120/240 Volts AC. This capability is crucial in handling potential fault scenarios and maintaining system integrity. The actuator is a handle type, allowing for straightforward operation.
