A0J2HCPU
A CPU unit created for industrial automation applications is the Mitsubishi A0J2HCPU. This CPU unit has 480 points for input and output data, and it has a wide range of input and output capabilities. It offers an 8K program capacity, making it possible to construct intricate control logic. The execution of program instructions is quick and prompt thanks to the 1.25 microsecond basic command processing speed for LD commands. The A0J2HCPU is more adaptable for a variety of programming tasks because of its 32K of RAM memory capacity and support for a shift instruction of two words.
-
We sell industrial automation parts backed by our free 2-Year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for A0J2HCPU
| Manufacturer | Mitsubishi |
|---|---|
| Product Type | CPU unit |
| Product Line | A Series |
| Part Number | A0J2HCPU |
| Weight | 2.25 lbs (1.02 kg) |
| Input and output points | 480 points |
| Input / output data points | 480 points |
| Program capacity | 8K |
| Basic command processing speed (LD command) | 1.25 |
| RAM memory capacity | 32K, power supply |
| Shift instruction | 2 Words |
| Input points | 32 points |
| Input voltage | DC12V/DC24V/AC12V/AC24V |
| Current | 4mA (DC12V/AC12V), 8.5mA (DC24V/DC24V) |
| Response time | 30ms (DC12/24V) /35ms (AC12/24V) |
| Terminal station | 50 Point |
| Count input signal | DC5/12/24V, 2-5mA |
The A0J2HCPU is a strong CPU chip that Mitsubishi made with care for industrial control systems. This unit has 480 input and output points, which is a lot. This means that it can connect to a lot of gadgets and monitors. The CPU unit allows a total of 480 input and output data points, which allow for efficient data sharing and smooth contact between the control system and connected equipment. The A0J2HCPU has 8K of code space, which is plenty of room for creating complex control logic. The unit is quick and sensitive because it has a basic command processing speed of 1.25, which shows how quickly it runs program orders. With 32 GB of RAM, the A0J2HCPU CPU is able to store and handle large amounts of data. It also works with shift instructions, which makes it easier to manipulate and process data. It has 32 input points and a wide range of input voltages, including DC12V, DC24V, AC12V, and AC24V. The input current ranges from 4 mA (DC12V/AC12V) to 8.5 mA (DC24V/AC24V), and the response time for input data is 30 ms (DC12/24V) or 35 ms (AC12V). The Mitsubishi A0J2HCPU is a reliable and flexible option for complex industrial control systems. It can handle up to 50 terminal stations and count input signals with DC5/12/24V at a range of 2–5 mA. In short, the Mitsubishi A0J2HCPU combines stable performance, flexible I/O capabilities, and efficient operation to meet the needs of complex industrial control systems. Its many features and advanced technology make it a top choice for automation apps that need to work well and be reliable.
- AOJ2HCPU
