A1SJ71E71N-B2
Mitsubishi produces the A1SJ71E71N-B2 Ethernet Interface Module, which is intended to offer connectivity for the Ans series. This module makes data transfer efficient by operating at a 10Mbps data transmission speed. It uses a 10BASE2 interface and offers half-duplex communication. The module provides a dependable and standardized method of creating network connections for industrial applications with the help of these requirements. Mitsubishi's dedication to providing connection solutions that satisfy the requirements of contemporary automation systems is demonstrated by its integration into the Ans series.
-
We sell industrial automation parts backed by our 2-year DO Supply Warranty.
-
Same-day domestic and fast international shipping with UPS, FedEx, DHL, and more.
-
AMEX, Visa, MasterCard, Discover, wire transfer, net terms, and more.
-
Repairs and exchanges are available for all automation products.
- Reseller Options
Drop shipping, blind shipping, and account shipping with no extra fees.
Technical specifications for A1SJ71E71N-B2
| Manufacturer | Mitsubishi |
|---|---|
| Product ID | a1sj71e71n-b2 |
| Product Type | Ethernet Interface Module |
| Series: | Ans |
| Interface: | 10BASE2 |
| Data Transmission Speed: | 10Mbps |
| Communication Mode: | Half Duplex |
| Transmission Method: | Baseband |
| Node-to-Node Distance: | 925m |
| Maximum Segment Length: | 185m (between hub and node) |
| Nodes/Connection: | 30/segment |
| Cascade Connection: | Up to 4 bases |
| Minimum Node-to-Node Distance: | 0.5m |
| Fixed Buffer: | 1k word × 8 |
| dimensions | 130mm (H) × 34.5mm (W) × 94mm (D) |
A remarkable development by Mitsubishi is the A1SJ71E71N-B2, an Ethernet Interface Module specifically designed for PLC applications. This module, which is a part of the Ans series, excels with its networking skills. It operates as a digital bridge, seamlessly connecting devices through a 10BASE2 interface. It facilitates the transmission of information across digital landscapes at a data transfer rate of 10Mbps, ensuring rapid and precise exchanges. The A1SJ71E71N-B2 employs half-duplex communication technology to prevent simultaneous overlapping conversations, thereby facilitating smooth communication. The module's preference for baseband transmission highlights its skill in ensuring safe and reliable data delivery. It features a node-to-node distance of 925 metres, encompassing a wide range of connections, and a vast segment length of 185 metres, underscoring its adaptability to various network configurations. This module is particularly versatile, supporting connections of up to 30 nodes per connection and cascading connections of up to 4 bases, extending the network's reach. This program communicates well in the language of effectiveness. It creates a seamless tapestry of data transmission in sequence programs with up to 8 simultaneous connections. It possesses optimized data dexterity with a fixed buffer of 1k words 8 and a random access buffer of 3k words. Its generous giving of 32 points per slot, topped with a unique 32-point I/O assignment, is its heartbeat for I/O points. It dances across connections with a BNC connector, a doorway to the digital world, and is powered by 0.66A at 5VDC. There are many alternatives for wiring, ranging from coaxial cables like RG58A/U or RG58C/U through the use of Category 3, 4, or 5 unshielded or shielded twisted pair (UTP/STP) cables. A 12V DC power source for the transceiver, a necessary life force for its operations, provides comfort to it along the way. Physically speaking, it is adaptable, with dimensions of 130mm (H), 34.5mm (W), and 94mm (D) and a weight of 0.21kg. It also fits into many ensembles without a hitch. The A1SJ71E71N-B2 functions essentially as an Ethernet conductor, coordinating connections and enabling smooth data exchanges with a dash of Mitsubishi brilliance.
