AJ35TB1-16D

The Mitsubishi AJ35TB1-16D is categorized as a MINI Remote I/O device designed to expand control capabilities for automation systems. This module hosts 16 direct current (DC) inputs and operates at a standard input voltage of 24 V DC. Each input consumes a modest current of 7 mA, which helps in minimizing overall energy consumption.

Equipped with opto-isolation technology, the AJ35TB1-16D protects connected devices by ensuring that electrical isolation is maintained, which enhances the safety and reliability of the system. Inputs respond quickly with a time of just 10 milliseconds, providing efficient data transmission. The module has a common configuration of 16 points, utilizing a single common terminal, and it supports both positive and negative poll arrangements (sink/source).

Connection is made through a 26-point terminal block, promoting straightforward wiring and setup. This module is designed to occupy 2 stations within a network, allowing flexible integration into existing structures. The input thresholds are set such that an ON condition requires a minimum voltage of 19 V DC, while an OFF state is maintained at a maximum of 6 V DC. Users can install the module on either DIN rails or by using screws, ensuring adaptability for different mounting scenarios. With its effective specifications, the AJ35TB1-16D serves as a robust solution for modern control systems.
