Mitsubishi F900GOT F930GOT-BWD-E

Product image is representative; revision or series may vary. Contact us to request a specific version.

F930GOT-BWD-E

|
Need a Specific Revision?

The Mitsubishi F930GOT-BWD-E MELSEC-GOT terminal is a graphic operation terminal (GOT) equipped with a versatile power supply. Its supply voltage rating is 24V DC, +10% to -15%, with a power ripple rating of 200 mV or less. Its current consumption rating is 200 mA at 24V DC (or 100 mA with the backlight off). The terminal features an STN monochrome liquid crystal display screen with two colors (blue and white) and a resolution of 240 × 80 dots. The terminal supports 500 user screens. It also supports a 15 × 4 matrix of switch touch keys or 50 touch keys/screen. The built-in memory includes 256 KB of flush memory for screen data and RAM for other data.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for F930GOT-BWD-E

ManufacturerMitsubishi
Product LineF900GOT
Part NumberF930GOT-BWD-E
Weight0.81 lbs (0.37 kg)
Model TypeGOT (graphic operation terminal)
Supply Voltage24V DC, +10% to -15%
Power Ripple200 mV or less
Current Consumption (24V DC)200 mA / 24V DC (backlight turned off: 100 mA / 24V DC)
BatteryBuilt-in lithium battery FX2NC-32B
Display Device/Display ColorSTN monochrome liquid crystal display, 2 colors (blue and white)
Resolution/Effective Display Size240 × 80 dots / 117 × 42 mm
Display Character (Full-Width)15 characters x 5 lines
Built-In Memory Type For Screen DataFlush memory / 256 KB
Built-In Memory For Other DataRAM (to back up current time and alarm history)
Ambient TemperatureOperation: 0 to +50 °C. Storage: -20 to +60°C
Ambient Humidity35 to 80%RH
Request a Repair

The Mitsubishi F930GOT-BWD-E interface terminal is a Graphic Operation Terminal (GOT) that provides a user-friendly interface for industrial automation systems. It is part of the MELSEC-GOT series. It requires a power supply with a supply voltage rating of 24V DC and a fluctuation rating of +10% to -15%. A separate service power supply from a PLC or a DC power supply should be prepared and used with the F930GOT-BWD-E terminal. The F930GOT-BWD-E terminal has a built-in fuse that cannot be replaced, and this fuse can withstand an allowable instant power interrupt rating of up to 5 ms. A lithium battery (FX2NC-32BL) is also integrated into the device. The performance specifications of the F930GOT-BWD-E terminal showcase its capabilities. The terminal features an STN monochrome liquid crystal screen with two colors, blue and white. The screen resolution is 240 × 80 dots, and the screen’s effective display size is 117 × 42 mm. Users can view 15 full-width characters on 5 lines on the screen, and the visible angle range is 30 degrees in all directions. The F930GOT-BWD-E terminal supports a maximum of 500 user screens, and the operators can create different user screens tailored to their application needs. The terminal can support a 15 × 4 matrix of touch keys or 50 touch keys per screen. The F930GOT-BWD-E terminal’s built-in memory includes 256 KB of flush memory for screen data in addition to RAM to back up the current time and alarm history data. The display element and backlight both have an average service life rating of 50,000 hours or more at room temperature (25 degrees Celsius) and typical room humidity. The backlight uses a cold cathode and includes an automatic “OFF” function that is adjustable through the PLC settings. The F930GOT-BWD-E terminal operates reliably within an ambient temperature range of 0 to +50 degrees Celsius and can be safely stored at temperatures from -20 to +60 degrees Celsius. The terminal can support an ambient humidity range of 35 to 80% RH without dew condensation. It can withstand up to 1,000 Vp-p of noise voltage, 1 microsecond of noise width, and a noise frequency rating of 30 to 100 Hz. With a withstand voltage rating of 500V AC for 1 minute between all the power terminals and the ground terminal, it ensures electrical safety. The F930GOT-BWD-E terminal has Class 3 grounding.
