Mitsubishi FX Series FX2N-32MR-ES/UL

Product image is representative; revision or series may vary. Contact us to request a specific version.

FX2N-32MR-ES/UL

|
Need a Specific Revision?

The FX2N-32MR-ES/UL from Mitsubishi functions as a base unit within the FX Series. It supports 32 I/O points and can handle an AC power supply ranging from 100 to 240V at 50/60 Hz.

In Stock
Ships from Raleigh, NC
2 Year DO Supply Warranty
Not an Authorized Distributor: DO Supply is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All of our products come with DO Supply's 2-year warranty.
Learn more

Technical specifications for FX2N-32MR-ES/UL

ManufacturerMitsubishi
Product TypeBase Unit
Product LineFX Series
Part NumberFX2N-32MR-ES/UL
Weight2.19 lbs (0.99 kg)
SeriesMELSEC-F, FX2N
Power Supply TypeAC Power Supply
Total I/O32 I/O
Number of Inputs16
Input TypeSink/Source (Selectable)
Number of Outputs16
Output TypeRelay
Power Supply Ratings100-240V AC, 50/60 Hz
Request a Repair

The FX2N-32MR-ES/UL is a foundational component in the Mitsubishi FX Series, designed explicitly for the MELSEC-F line. The FX2N-32MR-ES/UL base unit manages 32 input/output capabilities, providing a versatile platform for various control tasks. It is powered by an AC supply, with voltage specifications ranging between 100 and 240 volts AC, suitable for both 50 Hz and 60 Hz frequencies.

The FX2N-32MR-ES/UL base unit includes 16 input channels, which offer the flexibility of either a sink or source configuration, allowing adaptation for different switching requirements. In addition, the unit incorporates 16 outputs, which use relay technology for control functions. The physical size of the FX2N-32MR-ES/UL base unit is compact, measuring approximately 3.4 inches in height, 3.5 inches in width, and 5.9 inches in depth, fitting well into various operational environments.
