MDS-C1-SP-260

The Mitsubishi MDS-C1-SP-260 is a spindle drive unit engineered for rigorous applications. It can produce a rated output of 22 kW, suitable for demanding industrial tasks. Designed to function in an operating temperature spectrum of 0 to 55 °C, it can handle storage conditions ranging from -15 to 70 °C, ensuring flexibility in various environments. This unit remains operational up to an altitude of 1000 m, accommodating diverse installation settings.

Humidity levels can reach up to 90% RH, provided there is no dew condensation, which adds to its versatility in less-than-ideal conditions. With a weight of 6.3 kg, the spindle drive uses forced wind cooling for its heat management, maintaining efficiency during operation. The noise level registered is less than 55 dB, ensuring a quieter work environment.

For control functions, the MDS-C1-SP-260 employs a sine wave PWM control method along with current control technology, promoting higher precision in motor responses. The unit also includes regenerative braking, contributing to energy efficiency during operations. External analog outputs are available, operating within a range of 0 to +10V across two channels, allowing for flexible interfacing with additional components. With an overall protection rating of IP20 and IP00 at the terminal block TE1, this spindle drive unit is designed to operate reliably within specified parameters.
